Tractor · 2000Unverified

John Deere 8410T

Name: John Deere 8410T
Brand: John Deere

John Deere 8410T — Agricultural Crawler tractor · 237 hp. Reference specifications; pending source verification.

The John Deere 8410T is a tractor model with a rating of approximately 237 hp, placing it at the higher end of its class in terms of power. Its production spanned from 2000 to 2001. The 8410T features a 6-cylinder turbocharged diesel liquid-cooled engine, paired with a tracked undercarriage and a hydrostatic transmission. It has an operating weight of 23650 to 26380 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

237 hp

Max power

201.8 kW

Weight

23650 to 26380 pounds

Catalogue coverage

Variants represented

Richest spec table

74 rows

Recorded power

237 hp

Transmissions

16-speed full powershift

Production years

2000-2001

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Agricultural Crawler tractorReference

Built in Waterloo, Iowa, USAReference

DrivecrawlerReference

SteeringhydrostaticReference

Hydraulic wet disc brakesReference

CommandView cab standard with heat and A/C. Optional dexlue cab with rear windshield wiper, additional lights, mirror, and sun visor.Reference

Variants

8410wheeled tractorReference

8410Tcrawler tractorReference

Engine

John Deere 8.1L 6-cylReference

Drawbar (tested)153.5 kWReference

John DeereReference

turbocharged aftercooledReference

6-cylinderReference

liquid-cooledReference

Displacement8.1 LReference

Bore/Stroke116 x 129 mmReference

Air cleanertwo paper elementsReference

Compression16.5:1Reference

Rated RPM2200Reference

Starter volts12Reference

Coolant capacity34.0 LReference

Oil capacity27.0 LReference

Max power201.8 kWReference

Power at rated engine speed176.5 kWReference

Max power153.5 kWReference

Transmission

16-speed full powershiftReference

Typefull powershiftReference

Gears16 forward and 4 reverseReference

Oil capacity246.1 LReference

PTO & Hydraulics

PTO (claimed)175.2 kWReference

PTO (tested)201.8 kWReference

Hydraulic system246.0 LReference

Typepressure/flow compensated (PFC)Reference

Capacity246.0 LReference

Pressure200.0 barReference

Valves3 to 5Reference

Pump flow113.6 lpmReference

Total flow126.8 lpmReference

Total flow160.9 lpmReference

Rear TypeIII/IIINReference

Rear lift7098 kgReference

Rear PTOindependentReference

Rear PTO Type1000Reference

Capacities

Fuel492.1 LReference

Max capacity14288 kgReference

Dimensions

Wheelbase226 cmReference

Weight23650 to 26380 poundsReference

16-inch tracksReference

Length525 cmReference

Width263 cmReference

Height312 cmReference

Ground clearance44 cmReference

Ground clearance55 cmReference

Shipping10727 kgReference

Operating11965 kgReference

Ballasted13061 kgReference

Electrical

Charging systemalternatorReference

Charging amps140Reference

Batteries2Reference

Battery CCA1850Reference

Battery volts12Reference

John Deere 8410T Tracks

Width40 cmReference

Width45 cmReference

Width60 cmReference

Width76 cmReference

Test results

Diesel 16-speed crawlerApril 7 - 27, 2000Link: OCED Tractor Test 1778 fileReference

PTO performanceReference

Fuel use55.3 l/hourReference

Fuel use51.9 l/hourReference

Drawbar performanceReference

Gear 10 used for power test.Reference

Max pull12352 kgReference

Gear 3 used for pull test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
