Tractor · 1996Unverified

John Deere 846

Name: John Deere 846
Brand: John Deere

John Deere 846 — 46 Series · 27 hp. Reference specifications; pending source verification.

The John Deere 846 is a compact tractor rated at 27 hp, featuring a 3-cylinder diesel liquid-cooled engine. Manufactured from 1996 to 2003, it is equipped with a four-wheel drive system and a 12-speed gearbox. The tractor's listed weight is 1080 kg and is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

27 hp

Weight

1080 kg

Catalogue coverage

Variants represented

Richest spec table

40 rows

Recorded power

27 hp

Recorded weight

1080 kg

Transmissions

12-speed synchronized

Production years

1996-2003

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorJohn DeereReference

ManufacturerGoldiniReference

Compact Utility tractorReference

Built in ItalyReference

The John Deere 946 is similar to the Goldoni Idea 26.Reference

Four-wheel driveReference

Differential lockhydraulic rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Lombardini 1.3L 3-cyl dieselReference

Fuel tank20.1 LReference

Engine20.1 kWReference

LombardiniReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.3 LReference

Power20.1 kWReference

Air cleanerdryReference

Rated RPM2800Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed synchronizedReference

TypesynchronizedReference

Gears12 forward and 4 reverseReference

Clutch191mm hydraulic discReference

Four gears in three ranges, plus reverse range.Reference

PTO & Hydraulics

Rear TypeINReference

Rear lift (at ends)1000 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Engine RPM540@2607Reference

Engine RPM1000@2615Reference

Dimensions

Wheelbase151 cmReference

Weight1080 kgReference

Length274 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
