John Deere 8650
John Deere 8650 — Four-wheel Drive (4WD) tractor · 239 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
239 hp
Max power
164.0 kW
Weight
29320 to 30270 pounds
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Four-wheel Drive (4WD) tractorReference
Built in Waterloo, Iowa, USAReference
Original price was $97,562 in 1983Reference
The 8650 was the middle model of John Deere's 50-series four-wheel drive tractors that were first available in 1982. Efficiency was the advertising focus, noting that these tractors could be used throughout the season, not simply for tillage. The 8650 was able to plant and cultivate 30-inch rows, and perform a variety of field operations with its draft-control hitch and full-power PTO.Reference
Four-wheel driveReference
Final drivesinboard planetaryReference
Differential lockelectro-hydraulic front and rearReference
Articulated power steeringReference
Hydraulic wet disc brakesReference
Sound-Gard cab with air-conditioningReference
Engine
John Deere 10.1L 6-cyl dieselReference
Engine216.3 kWReference
Drawbar (tested)164.0 kWReference
John DeereReference
intercooled turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement10.1 LReference
Bore/Stroke130 x 127 mmReference
Power216.3 kWReference
Air cleanerdual paper elements with aspiratorReference
Compression15.2:1Reference
Rated RPM2100Reference
Starter volts12Reference
Oil capacity26.5 LReference
Coolant capacity45.4 LReference
Power at rated engine speed177.9 kWReference
Max power164.0 kWReference
Transmission
16-speed partial power shiftReference
TransmissionQuad-RangeReference
Typepartial power shiftReference
Gears16 forward and 6 reverseReference
ClutchPerma-Clutch hydraulic wet discsReference
Oil capacity142.0 LReference
Tractor must be stopped to select one of four ranges. Clutchless power shift between speeds 1-2 and 3-4 in range. A synchronized shift (using clutch) can be made between 2 and 3 in range.Reference
PTO & Hydraulics
PTO (claimed)175.2 kWReference
PTO (tested)177.9 kWReference
Hydraulic system141.9 LReference
Typeclosed center constant-pressureReference
Capacity141.9 LReference
Valves2 to 4Reference
Pump flow121.1 lpmReference
Rear TypeIII/IIINReference
Controllower-link draft sensingReference
Rear lift4200 kgReference
Rear PTOindependentReference
Clutchhydraulic wet discReference
Rear PTO Type1000 (1.75)Reference
Capacities
Fuel810.0 LReference
Dimensions
Wheelbase317 cmReference
Weight29320 to 30270 poundsReference
Front tire18.4-38Reference
Rear tire18.4-38Reference
Ag front18.4-38Reference
Ag rear18.4-38Reference
Ag front24.5-32Reference
Ag front24.5R32Reference
Ag front30.5-32Reference
Ag front30.5R32Reference
Ag front20.8-34Reference
Ag front23.1-34Reference
Ag front20.8-38Reference
Ag rear24.5-32Reference
Ag rear24.5R32Reference
Ag rear30.5-32Reference
Ag rear30.5R32Reference
Ag rear20.8-34Reference
Ag rear23.1-34Reference
Ag rear20.8-38Reference
Length567 cmReference
Shipping weight13299 kgReference
Operating weight13730 kgReference
Front axle100 by 2438 mmReference
Front axle99 by 3012 mmReference
Standard axle rear axle100 by 2438 mmReference
Long axle rear axle99 by 3012 mmReference
Front tread167 to 327 cmReference
Rear tread167 to 327 cmReference
John Deere 8650 attachments
bladeReference
8650 Serial Numbers
Location:Serial number plate on the rear of the tractor.Reference
19821500Reference
19833000Reference
19845001Reference
19857001Reference
19868001Reference
19878501Reference
19889001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps110Reference
Batteries2Reference
Battery CCA975Reference
Battery volts6Reference
Test results
Diesel 16-speed 4WDMay 13 - 24, 1982Link: Nebraska Tractor Test 1435 fileReference
PTO performanceReference
Fuel use58.3 l/hourReference
Drawbar performanceReference
Max pull12817 kgReference
Speeds
18.4-38 tiresReference
