Tractor · 2009Unverified
John Deere 90F
John Deere 90F — Milenio F Series · 82 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
82 hp
Weight
2679 kg
Hover a source tag to verify
Overview
DistributorJohn DeereReference
ManufacturerGoldiniReference
Orchard/Vineyard tractorReference
Built in ItalyReference
Four-wheel driveReference
Power steeringReference
Disc brakesReference
Two-post mid-mount folding ROPS.Reference
Engine
John Deere 4.5L 4-cyl dieselReference
Engine (gross)61.1 kWReference
John DeereReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke106 x 127 mmReference
Rated Power (gross)61.1 kWReference
Rated RPM2500Reference
Torque290.0 NmReference
StarterelectricReference
Starter volts12Reference
Transmission
16-speedReference
8-speedReference
Gears16 forward and 8 reverseReference
Gears8 forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Pump flow29.9 lpmReference
Pump flow50.0 lpmReference
Rear TypeII/IReference
Rear lift (at ends)2500 kgReference
Rear PTO Type540/540EReference
Dimensions
Wheelbase203 cmReference
Weight2679 kgReference
Front tire380/70-24Reference
Rear tire420/70-24Reference
Standard tires (ag)Front: 380/70-24. Rear: 420/70-24Reference
Length320 cmReference
Height218 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
