Tractor · 1967Unverified
John Deere 920
John Deere 920 — Utility tractor · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Weight
1973 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Utility tractorReference
Built in Mannheim, Baden-Württemberg, GermanyReference
Two-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Open operator station.Reference
Engine
John Deere 2.5L 3-cyl dieselReference
Engine (gross)27.6 kWReference
Engine (net)27.6 kWReference
John DeereReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke98 x 110 mmReference
Power (net)27.6 kWReference
Power (gross)27.6 kWReference
Compression16.7:1Reference
Rated RPM2300Reference
Idle RPM650-2440Reference
Operating RPM1300-2300Reference
Firing order1-2-3Reference
Starter volts12Reference
Oil capacity6.6 LReference
Coolant capacity10.4 LReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 4 reverseReference
Oil capacity37.9 LReference
PTO & Hydraulics
PTO (claimed)24.6 kWReference
Hydraulic system37.9 LReference
Capacity37.9 LReference
Pressure137.9 barReference
Rear TypeIReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2100Reference
Mid PTOliveReference
Mid PTO Type1000Reference
Capacities
Fuel62.5 LReference
Dimensions
Wheelbase188 cmReference
Weight1973 kgReference
Front tire6.00-16Reference
Rear tire9.5/9-36Reference
Ag front6.00-16Reference
Ag rear9.5/9-36Reference
Ag front5.50-16Reference
Ag rear11.2/10-36Reference
Ag rear12.4/11-28Reference
Ag rear12.4-11-32Reference
Length342 cmReference
Width150 cmReference
Height (steering wheel)145 cmReference
Height (exhaust)199 cmReference
Shipping weight1973 kgReference
John Deere 920 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Speeds
With 9.5/9-36 rear tires and 25 kph option.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
