Tractor · 2000Unverified
John Deere 9400T
John Deere 9400T — Agricultural Crawler tractor · 300 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
300 hp
Max power
258.4 kW
Weight
19332 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Agricultural Crawler tractorReference
Built in Waterloo, Iowa, USAReference
DrivecrawlerReference
Steeringelectro-hydraulicReference
Wet disc brakesReference
Cab standardReference
Variants
9400wheeled tractorReference
9400TcrawlerReference
Engine
John Deere 12.5L 6-cyl dieselReference
Engine316.9 kWReference
Drawbar (tested)241.2 kWReference
John DeereReference
turbocharged dieselReference
6-cylinderReference
liquid-cooled verticalReference
Displacement12.5 LReference
Bore/Stroke127 x 165 mmReference
Power316.9 kWReference
Air cleanerdual paper elementsReference
Compression17:1Reference
Rated RPM2100Reference
Starter volts12Reference
Max power258.4 kWReference
Power at rated engine speed223.5 kWReference
Max power241.2 kWReference
Transmission
24-speed partial power shiftReference
TransmissionPowrSyncReference
Typepartial power shiftReference
Gears24 forward and 6 reverseReference
PTO & Hydraulics
PTO (tested)258.4 kWReference
Rear TypeIII,IVReference
Rear PTO Type1000Reference
Power at rated PTO speed247.5 kWReference
Dimensions
Weight19332 kgReference
TracksReference
9400T Serial Numbers
Location:Under tractor cab door near steps.Reference
Test results
Diesel 24-speed crawlerMarch 27 - April 13, 2001Link: OCED Tractor Test 1791 fileReference
PTO performanceReference
Fuel use71.2 l/hourReference
Fuel use67.0 l/hourReference
Fuel use67.8 l/hourReference
Drawbar performanceReference
Fuel use76.1 l/hourReference
Max pull19242 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
