Tractor · 2015Unverified

John Deere 9520RT

John Deere 9520RT — 9R Series · 520 hp. Reference specifications; pending source verification.

The John Deere 9520RT is a tractor with a rated power output of 520 horsepower, positioning it at the more powerful end of its class. Manufactured in 2015, it features a 6-cylinder turbocharged diesel liquid-cooled engine, combined with four-wheel drive and a powershift transmission. The 9520RT has an operating weight of 20,371 kg. This model is suitable for operations covering 1,500 acres or more.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
520 hp
Weight
20371 kg

Catalogue coverage

Variants represented
2
Richest spec table
67 rows
Recorded power
520 hp
Recorded weight
20371 kg
Transmissions
18-speed full power shift
Production years
2015-2015
Verified variants
0

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference
Agricultural Crawler tractorReference
Built in Waterloo, Iowa, USAReference
DrivecrawlerReference
Power steeringReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Command View Cab III standard with air-conditioning. AutoTrac ready; ISOBUS 11783; JDLink readyReference

Variants

9520Rwheeled 4WDReference
9520RTcrawlerReference
9520RXarticulated crawlerReference

Engine

John Deere 13.5L 6-cyl dieselReference
Engine (gross)387.8 kWReference
Engine (max)426.5 kWReference
John Deere PSSReference
variable geometry turbocharger dieselReference
6-cylinderReference
liquid-cooledReference
Displacement13.5 LReference
Bore/Stroke132 x 165 mmReference
EmissionsTier IVReference
Emission controlselective catalytic reductionReference
Rated Power (gross)387.8 kWReference
Maximum Power (gross)426.5 kWReference
Compression16:1Reference
Rated RPM2100Reference
StarterelectricReference
Starter volts12Reference

Transmission

18-speed full power shiftReference
Transmissione18 PowerShiftReference
Typefull power shiftReference
Gears18 forward and 6 reverseReference

PTO & Hydraulics

PTO (claimed)245.3 kWReference
Hydraulic system300.2 LReference
Hydraulic system307.7 LReference
Typeclosed-center pressure/flow compensatedReference
Capacity300.2 LReference
Capacity307.7 LReference
Pressure200.0 barReference
Rear valves4 to 8Reference
Pump flow219.5 lpmReference
Pump flow435.3 lpmReference
SCV flow132.5 lpmReference
SCV flow159.0 lpmReference
Rear TypeIV/IVNReference
Rear lift6804 kgReference
Rear lift9072 kgReference
DrawbarCat. 5 HDReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type1000 (1.75)Reference

Capacities

Fuel1324.8 LReference
Exhaust fluid (DEF)83.3 LReference

Dimensions

Weight20371 kgReference
30-inch tracksReference
Clearance (drawbar)30480 cmReference
Shipping20371 kgReference
Ballasted24494 kgReference
Max Drawbar5443 kgReference
Max Drawbar4581 kgReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Batteries3Reference
Battery CCA925Reference
Battery volts12Reference

John Deere 9520RT Tracks

Width76 cmReference
Width91 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
