Industrial Tractor · 1936Unverified
John Deere AI
John Deere AI — Industrial tractor. Reference specifications; pending source verification.
The John Deere AI is an industrial tractor. This model was produced from 1936 to 1941. Under the hood is a 2-cylinder liquid-cooled engine, driving through two-wheel drive with a 4-speed gearbox. Listed weight is 2122 kg, and it is aimed at jobs of around varies. The available specification table below shows both UK and US units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Weight
2122 kg
Catalogue coverage
Variants represented
2
Richest spec table
30 rows
Recorded weight
2122 kg
Transmissions
4-speed gear
Production years
1936-1941
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Industrial tractorReference
Built in Waterloo, Iowa, USAReference
Total built68Reference
Two-wheel driveReference
Open operator station.Reference
Variants
ARfarm tractorReference
Engine
John Deere 5.1L 2-cyl all fuelReference
Fuel tank60.6 LReference
Aux. fuel3.8 LReference
John DeereReference
all fuelReference
2-cylinderReference
liquid-cooledReference
Displacement5.1 LReference
Bore/Stroke140 x 165 mmReference
Rated RPM975Reference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
Dimensions
Wheelbase175 cmReference
Weight2122 kgReference
Ag front6x16Reference
Ag rear19x24Reference
Length303 cmReference
Width154 cmReference
Height130 cmReference
Front tread119 cmReference
Rear tread129 cmReference
AI Serial Number Location
Serial number plate on the left side of the tractor, just ahead of the flywheel.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
