Tractor · 1927Unverified
John Deere C
John Deere C — Row-Crop tractor · 10 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Row-Crop tractorReference
Built in Waterloo, Iowa, USAReference
Total built92Reference
The Model C was the early version of what became the John Deere model GP. Tractors 200001 to 200110 were built from August 1927 to January 1928 and then recalled. Fifty-three of the pre-production models were rebuilt with new serial numbers. In June of 1928 a decision was made to re-name the tractor as the GP.Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
John Deere 5.1L 2-cyl keroseneReference
Drawbar (claimed)7.5 kWReference
Belt (claimed)14.9 kWReference
John DeereReference
keroseneReference
2-cylinderReference
liquid-cooledReference
Displacement5.1 LReference
Bore/Stroke146 x 152 mmReference
Rated RPM950Reference
Starter typemanualReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
C Serial Numbers
Location:Serial number plate on the transmission housing, below the gear shift lever.Reference
1927200001 (pre-production)Reference
1928200111Reference
Final200202Reference
FAQ: How to read a serial number table.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
