Lawn Tractor · 2004Unverified
John Deere CR125
John Deere CR125 — CR Series · 13 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
13 hp
Weight
165 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Riding lawn mowerReference
Two-wheel driveReference
SteeringmanualReference
Disc on transmission brakesReference
Open operator station.Reference
Engine
9.3KW Briggs & Stratton 344cc 1-cyl gasolineReference
Fuel tank4.0 LReference
Briggs & Stratton 21B807Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement21 ciReference
Power9.3 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
5-speed gearReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Typebelt-driven gearReference
Gears5 forward and 1 reverseReference
Dimensions
Wheelbase113 cmReference
Weight165 kgReference
Front tire11x4.00-4Reference
Rear tire15x6.00-6Reference
Lawn/turf front11x4.00-4Reference
Lawn/turf rear15x6.00-6Reference
Length186 cmReference
Width75 cmReference
Height (steering wheel)109 cmReference
John Deere CR125 attachments
72 cm mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
Battery AH18Reference
28.35" Mower deck
Typemid-mount John DeereReference
Cutting width72 cmReference
Cut height2 to 8 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
