Industrial Tractor · 1925Unverified
John Deere DI
John Deere DI — Industrial tractor · 27 hp. Reference specifications; pending source verification.
The John Deere DI is an industrial tractor with a rated output of 27 hp, classifying it as a compact option within its category. The model was manufactured from 1925 to 1941. It features a 2-cylinder petrol liquid-cooled engine, which drives through two-wheel drive with a 2-speed gearbox. The listed weight is 2390 kg and it is suited for tasks covering approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
27 hp
Weight
2390 kg
Catalogue coverage
Variants represented
2
Richest spec table
33 rows
Recorded power
27 hp
Recorded weight
2390 kg
Transmissions
2-speed gear
Production years
1925-1941
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Industrial tractorReference
Built in Waterloo, Iowa, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
Dfarm tractorReference
Engine
John Deere 8.2L 2-cyl gasolineReference
Fuel tank94.6 LReference
Aux. fuel5.7 LReference
Belt (claimed)20.1 kWReference
John DeereReference
gasolineReference
2-cylinderReference
liquid-cooledReference
Displacement8.2 LReference
Bore/Stroke171 x 178 mmReference
Compression3.91:1Reference
Rated RPM900Reference
Transmission
2-speed gearReference
3-speed gearReference
TypegearReference
Gears2 forward and 1 reverseReference
The two-speed transmission was used until 1937.Reference
Gears3 forward and 1 reverseReference
The three-speed transmission was introduced in 1937.Reference
Dimensions
Weight2390 kgReference
Ag front7.50x18Reference
Ag rear12.75x28Reference
Length330 cmReference
Width168 cmReference
Height155 cmReference
DI Serial Number Location
Serial number plate on the rear of the transmission case, below the gear shifter.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
