Tractor · 1950Unverified
John Deere GH
John Deere GH — Two-Cylinder Letter Series · 36 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
36 hp
Weight
3147 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
High-Clearance tractorReference
Built in Waterloo, Iowa, USAReference
Total built237Reference
Two-wheel driveReference
Manual steeringReference
Mechanical drum brakesReference
Open operator station.Reference
Variants
Grow-cropReference
GNsingle-frontReference
GWwide-frontReference
GHhigh-cropReference
Engine
John Deere 6.8L 2-cyl all-fuelReference
Fuel tank64.3 LReference
Aux. fuel5.7 LReference
Drawbar (claimed)26.9 kWReference
Belt (claimed)29.7 kWReference
John DeereReference
all-fuelReference
2-cylinderReference
liquid-cooledReference
Displacement6.8 LReference
Bore/Stroke156 x 178 mmReference
Compression4.2:1Reference
Rated RPM975Reference
StarterelectricReference
Starter volts12Reference
Oil capacity10.4 LReference
Coolant capacity41.6 LReference
Transmission
6-speed gearReference
TransmissionJohn DeereReference
TypegearReference
Gears6 forward and 1 reverseReference
Clutchdry discReference
PTO & Hydraulics
Typeopen centerReference
Pump flow4.7 lpmReference
Rear PTOtransmissionReference
Rear PTO Type540Reference
Dimensions
Weight3147 kgReference
Front tire7.50-20Reference
Rear tire12-38Reference
Ag front7.50-20Reference
Ag rear12-38Reference
Shipping weight3147 kgReference
Front tread152 to 213 cmReference
Rear tread152 to 228 cmReference
GH Serial Number Location
Serial number plate on the casting above the belt pully.Reference
Electrical
GroundpositiveReference
Charging systemgenerationReference
Batteries2Reference
Battery volts6Reference
Speeds
With 12-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
