Lawn Tractor · 2009Unverified

John Deere LA155

John Deere LA155 — LA105 Series · 22 hp. Reference specifications; pending source verification.

The John Deere LA155 is a lawn tractor with a rated output of 22 hp, categorising it among the higher-powered machines in its class. It was manufactured from 2009 to 2010. The model features a 2-cylinder petrol air-cooled engine, which drives two-wheel drive through a hydrostatic transmission. Its listed weight is 238 kg, and it is suitable for tasks of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
22 hp
Weight
238 kg

Catalogue coverage

Variants represented
2
Richest spec table
58 rows
Recorded power
22 hp
Recorded weight
238 kg
Transmissions
hydrostatic
Production years
2009-2010
Verified variants
0

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference
Lawn tractorReference
Built in Greeneville, Tennessee, USAReference
Original price was $2,349 in 2010Reference
Two-wheel driveReference
Manual steeringReference
Open operator station. Adjustable seat (10 position, 5.5-inches travel) and cup holder. Optional nylon canopy.Reference

Engine

22HP Briggs & Stratton 655cc 2-cyl gasolineReference
Fuel tank15.1 LReference
Fuel tank8.5 LReference
Briggs & StrattonReference
gasolineReference
2-cylinderReference
air-cooledReference
Displacement40 ciReference
Bore/Stroke75 x 73 mmReference
Power (gross)16.4 kWReference
Air cleanerpaper and foam elementsReference
Starter volts12Reference
Sparkplug gap0.762 mmReference
Point gap0.254 mmReference
Intake valve clearance0.127 mmReference
Exhaust valve clearance0.127 mmReference
Oil capacity1.8 LReference

Transmission

hydrostaticReference
TransmissionTuff Torq T40JReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil changesealed unit, owner service is not recommendedReference

Dimensions

Wheelbase124 cmReference
Weight238 kgReference
Front tire15x6-6Reference
Rear tire20x10-8Reference
Lawn/turf front15x6-6Reference
Lawn/turf rear20x10-8Reference
Length188 cmReference
Width153 cmReference
Height116 cmReference

John Deere LA155 attachments

48" mid-mount mower deckReference
snowblowerReference
bladeReference

LA155 Serial Number Location

Serial number plate under the left-rear fender.Reference

LA155 Serial Numbers

2009200001Reference
2010300001Reference
FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference
Charging amps16Reference
Battery volts12Reference
Battery GroupU1Reference

Questions

I have a LA105 and I see a picture of the choke sign on the dash but have no clue where the knob or lever is. The choke is engaged at the full throttle position. Once the engine is running the throttle lever should be moved just below this position to disengage the choke.Reference

Attachment overview

48" mid-mount mower deckReference
SnowblowerReference
BladeReference

48" Mower deck

Typemid-mount John Deere 48 EdgeReference
Type3-blade with manual liftReference
Cutting width121 cmReference
Overall width152 cmReference
Cut height2 to 10 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
