Lawn Tractor · 1999Unverified

John Deere LTR166

Name: John Deere LTR166
Brand: John Deere

John Deere LTR166 — Rear-discharge mower · 16 hp. Reference specifications; pending source verification.

The John Deere LTR166 is a lawn tractor with a rated output of 16 hp, positioning it towards the middle of its class in terms of power. It was manufactured between 1999 and 2001. The machine features a 2-cylinder petrol air-cooled engine, driving through a two-wheel drive system with a hydrostatic transmission. Its listed weight is 273 kg and is suitable for areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

16 hp

Weight

273 kg

Catalogue coverage

Variants represented

Richest spec table

45 rows

Recorded power

16 hp

Recorded weight

273 kg

Transmissions

hydrostatic

Production years

1999-2001

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Rear-discharge mowerReference

Built in Horicon, Wisconsin, USAReference

Original price was $3,799 in 2001Reference

Two-wheel driveReference

Manual steeringReference

Open operator station.Reference

Variants

LT166lawn tractorReference

LTR166rear-discharge mowerReference

Engine

16HP Briggs & Stratton 480cc 2-cyl gasolineReference

Fuel tank7.6 LReference

Briggs & Stratton 303777Reference

gasolineReference

2-cylinderReference

air-cooled vertical-shaft V-TwinReference

Displacement29.3 ciReference

Bore/Stroke68 x 66 mmReference

Power (gross)11.9 kWReference

Starter volts12Reference

Sparkplug gap1.016 mmReference

Oil capacity2.0 LReference

Oil change50 hReference

Transmission

hydrostaticReference

TransmissionTuff Torq K51AReference

Typebelt-driven hydrostaticReference

Gearsinfinite forward and reverseReference

Oil changesealed unit, owner service is not recommendedReference

PTO & Hydraulics

Mid PTOindependentReference

ClutchmanualReference

Dimensions

Weight273 kgReference

Length172 cmReference

Length237 cmReference

Height103 cmReference

John Deere LTR166 attachments

42" mid-mount mower deckReference

LTR166 Serial Numbers

Location:Serial number decal on the left side of the console pedestal, under the hood.Reference

1999010001Reference

2000020001Reference

2001030001Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Battery volts12Reference

42" Mower deck

Typemid-mount John deereReference

Type2-blade with manual liftReference

Cutting width106 cmReference

Cut height1 to 8 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
