Industrial Tractor · 1949Unverified
John Deere MI
John Deere MI — Industrial tractor · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
1360 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Industrial tractorReference
Built in Dubuque, Iowa, USAReference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Variants
Mfarm tractorReference
MTtricycle-frontReference
MCcrawlerReference
Engine
John Deere 1.6L 2-cyl gasolineReference
Fuel tank37.9 LReference
Belt (claimed)14.9 kWReference
John DeereReference
gasolineReference
2-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke102 x 102 mmReference
Rated RPM1650Reference
Firing order1-2Reference
Oil capacity4.7 LReference
Coolant capacity13.2 LReference
Sparkplug gap0.635 mmReference
Point gap0.559 mmReference
Intake valve clearance0.305 mmReference
Exhaust valve clearance0.305 mmReference
Transmission
4-speedReference
TransmissiongearReference
Gears4 forward and 1 reverseReference
Dimensions
Weight1360 kgReference
Ag front5.00x15Reference
Ag rear9.00x24Reference
Ag front5.00x16Reference
Ag front6.00x16Reference
Ag rear10.00x24Reference
Length279 cmReference
Width157 cmReference
Height148 cmReference
MI Serial Number Location
Serial number plate mounted below steering wheel.Reference
MI Serial Numbers
195010001 (model year)Reference
195110293Reference
195210685Reference
Final11032Reference
FAQ: How to read a serial number table.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
