Tractor · 1968Unverified
John Deere WA-14
John Deere WA-14 — Four-wheel Drive (4WD) tractor · 225 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
225 hp
Weight
12029 kg
Hover a source tag to verify
Overview
DistributorJohn DeereReference
ManufacturerWagnerReference
Four-wheel Drive (4WD) tractorReference
Built in Portland, Oregon, USAReference
Total built23Reference
Original price was $35,990 in 1969Reference
Wagner was a tractor and logging machinery firm in Oregon. Deere contracted with Wagner to build large four-wheel-drive tractors during the period after the 8020 and before the introduction of the 7020.Reference
Four-wheel driveReference
Final drivesplanetaryReference
SteeringpowerReference
Pneumatic brakesReference
Open operator station. Cab optional. Heat and air-conditioning optional.Reference
Engine
Cummins 14.0L 6-cyl dieselReference
Engine167.8 kWReference
Drawbar (claimed)132.7 kWReference
Cummins N855C1Reference
dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement14.0 LReference
Bore/Stroke140 x 152 mmReference
Power167.8 kWReference
Air cleanerdryReference
Compression14.9:1Reference
Rated RPM2100Reference
Starter volts24Reference
Coolant capacity47.3 LReference
Oil capacity37.9 LReference
Oil change200 hReference
Transmission
10-speedReference
TransmissionFuller RTO-910Reference
Gears10 forward and 2 reverseReference
Clutch355.6mm dry discsReference
Five forward and one reverse with air-assist hi/lo range selection. Shifting on the move possible by double clutching.Reference
Capacities
Fuel454.2 LReference
Steering151.4 LReference
PTO & Hydraulics
Hydraulic system196.8 LReference
Typeopen centerReference
Capacity196.8 LReference
Valves2 or 3Reference
Pump flow56.8 lpmReference
Pump flow132.5 lpmReference
Total flow170.3 lpmReference
Total flow246.0 lpmReference
Steering flow113.6 lpmReference
Steering cap.151.4 LReference
Dimensions
Wheelbase345 cmReference
Weight12029 kgReference
Front tire23.1-30Reference
Rear tire23.1-30Reference
Ag front23.1-30Reference
Ag rear23.1-30Reference
Ag front18.4-34Reference
Ag rear18.4-34Reference
Length652 cmReference
Width264 cmReference
Height251 cmReference
Height (cab)330 cmReference
Ground clearance48 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Batteries2Reference
Battery volts12Reference
Battery AH205Reference
Battery Group8DReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
