Lawn Tractor · 2018Unverified
John Deere X116R
John Deere X116R — X100 Series · 10 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Weight
224 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Rear-discharge mowerReference
Built in Greeneville, Tennessee, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
7.6KW Briggs & Stratton 339cc 1-cyl gasolineReference
Fuel tank7.6 LReference
Briggs & Stratton 21R877Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement20.74 ciReference
Bore/Stroke87 x 57 mmReference
Power7.6 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity1.4 LReference
Transmission
hydrostaticReference
TransmissionTuff Torq K46Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Wheelbase122 cmReference
Weight224 kgReference
Front tire15x6.00-6Reference
Rear tire18x8.5-8Reference
Lawn/turf front15x6.00-6Reference
Lawn/turf rear18x8.5-8Reference
Length246 cmReference
Width107 cmReference
John Deere X116R attachments
91 cm mid-mount mower deckReference
Electrical
GroundnegativeReference
Charging amps9Reference
Battery volts12Reference
Battery GroupU1Reference
36" Mower deck
Typemid-mount John DeereReference
Type2-blade with manual liftReference
Cutting width91 cmReference
Overall width96 cmReference
Cut height2 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
