Lawn Tractor · 2018Unverified
John Deere X126
John Deere X126 — X100 Series · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Weight
210 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Lawn tractorReference
Built in Greeneville, Tennessee, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
10.7KW Briggs & Stratton 499cc 1-cyl gasolineReference
Fuel tank9.1 LReference
Briggs & Stratton 31Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement30.5 ciReference
Bore/Stroke90 x 78 mmReference
Power10.7 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity1.4 LReference
Transmission
hydrostaticReference
TransmissionTuff Torq TLT200Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Wheelbase122 cmReference
Weight210 kgReference
Front tire15x6.00-6Reference
Rear tire20x8.0-8Reference
Lawn/turf front15x6.00-6Reference
Lawn/turf rear20x8.0-8Reference
Length187 cmReference
Height104 cmReference
John Deere X126 attachments
106 cm mid-mount mower deckReference
Electrical
GroundnegativeReference
Charging amps9Reference
Battery volts12Reference
Battery GroupU1Reference
42" Mower deck
Typemid-mount John Deere 42 EdgeReference
Type2-blade with manual liftReference
Cutting width106 cmReference
Overall width132 cmReference
Cut height2 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
