Lawn Tractor · 2010Unverified

John Deere X130R

Name: John Deere X130R
Brand: John Deere

John Deere X130R — X100 Series · 17 hp. Reference specifications; pending source verification.

The John Deere X130R lawn tractor is powered by a 17 hp engine, positioning it in the middle of its class in terms of power output. Manufactured in 2010, it is equipped with a 2-cylinder petrol air-cooled engine and features a hydrostatic transmission with two-wheel drive. The model weighs 208 kg and is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

17 hp

Weight

208 kg

Catalogue coverage

Variants represented

Richest spec table

47 rows

Recorded power

17 hp

Recorded weight

208 kg

Transmissions

hydrostatic

Production years

2010-2010

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Lawn tractorReference

Built in Greeneville, Tennessee, USAReference

Two-wheel driveReference

SteeringmanualReference

Open operator station.Reference

Engine

12.5KW Briggs & Stratton 655cc 2-cyl gasolineReference

Fuel tank7.6 LReference

Briggs & Stratton 4055Reference

gasolineReference

2-cylinderReference

air-cooledReference

Displacement40 ciReference

Bore/Stroke75 x 73 mmReference

Power (gross)12.5 kWReference

Air cleanerpaper and foamReference

StarterelectricReference

Starter volts12Reference

Sparkplug gap0.762 mmReference

Point gap0.254 mmReference

Intake valve clearance0.127 mmReference

Exhaust valve clearance0.127 mmReference

Oil capacity1.9 LReference

Transmission

hydrostaticReference

TransmissionTuff Torq T40Reference

TypehydrostaticReference

PTO & Hydraulics

Front PTOindependentReference

ClutchelectricReference

Dimensions

Weight208 kgReference

Front tire15x6.00-6Reference

Rear tire18x8.5-8Reference

Lawn/turf front15x6.00-6Reference

Lawn/turf rear18x8.5-8Reference

Length251 cmReference

Width111 cmReference

Height111 cmReference

John Deere X130R attachments

106 cm mid-mount mower deckReference

Electrical

GroundnegativeReference

Charging systemregulated circuitReference

Charging amps9Reference

Battery volts12Reference

Battery GroupBCI U1Reference

42" Mower deck

Typemid-mount John Deere 42CReference

Type2-blade with manual liftReference

Cutting width106 cmReference

Overall width131 cmReference

Cut height2 to 10 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
