Lawn Tractor · 2013Unverified
John Deere X135R
John Deere X135R — X100 Series · 12 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
12 hp
Weight
233 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Rear-discharge mowerReference
Built in Greeneville, Tennessee, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
8.8KW Briggs & Stratton 655cc 2-cyl gasolineReference
Fuel tank7.6 LReference
Briggs & StrattonReference
gasolineReference
2-cylinderReference
air-cooled vertical-shaftReference
Displacement40 ciReference
Bore/Stroke75 x 73 mmReference
Power (gross)8.8 kWReference
Rated RPM3150Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TransmissionTuff Torq K46CYReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil changesealed unit, owner service is not recommendedReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase122 cmReference
Weight233 kgReference
Front tire15x6-6Reference
Rear tire18x8.5-8Reference
Lawn/turf front15x6-6Reference
Lawn/turf rear18x8.5-8Reference
Length247 cmReference
Width96 cmReference
Height107 cmReference
John Deere X135R attachments
106 cm mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
42" Mower deck
Typemid-mount John DeereReference
Typemanual liftReference
Cutting width106 cmReference
Cut height2 to 8 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
