Lawn Tractor · 2021Unverified
John Deere X147R
John Deere X147R — X100 Series · 17 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
239 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Rear-discharge mowerReference
Built in Greeneville, Tennessee, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
12.6KW Briggs & Stratton 655cc 2-cyl gasolineReference
Fuel tank7.6 LReference
Briggs & Stratton 40N877Reference
gasolineReference
2-cylinderReference
air-cooled vertical-shaft V-TwinReference
Displacement40 ciReference
Bore/Stroke75 x 73 mmReference
Power12.6 kWReference
StarterelectricReference
Starter volts12Reference
Oil capacity2.6 LReference
Oil change50 hReference
Sparkplug gap0.762 mmReference
Transmission
hydrostaticReference
TransmissionTuff Torq K46EEReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil changesealed unit, owner service is not recommendedReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Weight239 kgReference
Front tire15x6-6Reference
Rear tire18x18.5-8Reference
Lawn/turf front15x6-6Reference
Lawn/turf rear18x18.5-8Reference
Length242 cmReference
Width96 cmReference
Height102 cmReference
John Deere X147R attachments
91 cm mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Charging amps9Reference
Battery volts12Reference
Battery GroupU1Reference
Attachment overview
91 cm mid-mount mower deckReference
SnowblowerReference
BladeReference
The X147R is equipped with a 300 liter rear collection system.Reference
36" Mower deck
Typemid-mount John DeereReference
Type2-blade with manual liftReference
Cutting width91 cmReference
Cut height2 to 8 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
