Lawn Tractor · 2011Unverified

John Deere X165

Name: John Deere X165
Brand: John Deere

John Deere X165 — X100 Series · 18 hp. Reference specifications; pending source verification.

The John Deere X165 is a lawn tractor model with a rated output of 18 hp, positioning it in the middle of its class for power. It was manufactured from 2011 to 2017. The model features a 2-cylinder petrol air-cooled engine, which powers a two-wheel drive system with hydrostatic transmission. The listed weight of the X165 is 237 kg, and it is suitable for tasks covering areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

18 hp

Weight

237 kg

Catalogue coverage

Variants represented

Richest spec table

47 rows

Recorded power

18 hp

Recorded weight

237 kg

Transmissions

hydrostatic

Production years

2011-2017

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Lawn tractorReference

Built in Greeneville, Tennessee, USAReference

Two-wheel driveReference

SteeringmanualReference

Open operator station.Reference

Engine

13.3KW Briggs & Stratton 655cc 2-cyl gasolineReference

Fuel tank14.8 LReference

Briggs & Stratton 40Reference

gasolineReference

2-cylinderReference

air-cooledReference

Displacement40 ciReference

Bore/Stroke75 x 73 mmReference

Power (gross)13.3 kWReference

Air cleanerpaper and foamReference

StarterelectricReference

Starter volts12Reference

Sparkplug gap0.762 mmReference

Point gap0.254 mmReference

Intake valve clearance0.127 mmReference

Exhaust valve clearance0.127 mmReference

Oil capacity1.9 LReference

Transmission

hydrostaticReference

TransmissionTuff Torq HD K46Reference

TypehydrostaticReference

PTO & Hydraulics

Front PTOindependentReference

ClutchelectricReference

Dimensions

Weight237 kgReference

Front tire16x6.5-8Reference

Rear tire22x9.5-12Reference

Lawn/turf front16x6.5-8Reference

Lawn/turf rear22x9.5-12Reference

Length175 cmReference

Width152 cmReference

Height114 cmReference

John Deere X165 attachments

121 cm mid-mount mower deckReference

Electrical

GroundnegativeReference

Charging systemregulated circuitReference

Charging amps9Reference

Battery volts12Reference

Battery GroupBCI U1Reference

48" Mower deck

Typemid-mount John Deere 48CReference

Type3-blade with manual liftReference

Cutting width121 cmReference

Overall width152 cmReference

Cut height2 to 10 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
