Lawn Tractor · 2011Unverified
John Deere X165
John Deere X165 — X100 Series · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
237 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Lawn tractorReference
Built in Greeneville, Tennessee, USAReference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Engine
13.3KW Briggs & Stratton 655cc 2-cyl gasolineReference
Fuel tank14.8 LReference
Briggs & Stratton 40Reference
gasolineReference
2-cylinderReference
air-cooledReference
Displacement40 ciReference
Bore/Stroke75 x 73 mmReference
Power (gross)13.3 kWReference
Air cleanerpaper and foamReference
StarterelectricReference
Starter volts12Reference
Sparkplug gap0.762 mmReference
Point gap0.254 mmReference
Intake valve clearance0.127 mmReference
Exhaust valve clearance0.127 mmReference
Oil capacity1.9 LReference
Transmission
hydrostaticReference
TransmissionTuff Torq HD K46Reference
TypehydrostaticReference
PTO & Hydraulics
Front PTOindependentReference
ClutchelectricReference
Dimensions
Weight237 kgReference
Front tire16x6.5-8Reference
Rear tire22x9.5-12Reference
Lawn/turf front16x6.5-8Reference
Lawn/turf rear22x9.5-12Reference
Length175 cmReference
Width152 cmReference
Height114 cmReference
John Deere X165 attachments
121 cm mid-mount mower deckReference
Electrical
GroundnegativeReference
Charging systemregulated circuitReference
Charging amps9Reference
Battery volts12Reference
Battery GroupBCI U1Reference
48" Mower deck
Typemid-mount John Deere 48CReference
Type3-blade with manual liftReference
Cutting width121 cmReference
Overall width152 cmReference
Cut height2 to 10 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
