Lawn Tractor · 2008Unverified
John Deere X729
John Deere X729 — Select X700 Series · 27 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
27 hp
Weight
514 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Garden tractorReference
Original price was $11,149 in 2011Reference
Four-wheel driveReference
Steeringhydrostatic power, all-wheel steeringReference
Wet disc brakesReference
Open operator station featuring 18-inch seat with 7-inches of adjustment. Cupholder, toolbox, tilt steering, and 12-volt outlet standard. Optional soft-side or hard cab.Reference
Variants
X720two-wheel driveReference
X7242WD, all-wheel steerReference
X728four-wheel driveReference
X7294WD, all-wheel steerReference
Engine
27HP Kawasaki 745cc 2-cyl gasolineReference
Fuel tank24.6 LReference
Fuel tank19.7 LReference
Kawasaki FD750D EFIReference
gasolineReference
2-cylinderReference
liquid-cooled V-twinReference
Displacement45.5 ciReference
Bore/Stroke78 x 78 mmReference
Power (gross)20.1 kWReference
Fuel systemelectronic fuel injectionReference
Air cleanerdual paper elementReference
Compression8.5:1Reference
Idle RPM1600-3550Reference
Starter volts12Reference
Starter power0.8 kWReference
Coolant capacity4.0 LReference
Oil capacity1.8 LReference
Transmission
hydrostaticReference
TransmissionKanzakiReference
Typeshaft-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity6.8 LReference
Hydrostatic transmission with Twin Touch foot pedals and dashboard-mounted cruise control standard.Reference
1ThrottleReference
2BrakeReference
3ForwardReference
4ReverseReference
5Parking brakeReference
6Cruise controlReference
7Differential lockReference
PTO & Hydraulics
Pressure63.7 barReference
Valves2Reference
Total flow17.0 lpmReference
Rear Type0Reference
Rear Type1-LimitedReference
Rear PTOindependentReference
Rear PTO Type540Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Front PTOoptionalReference
Front PTO Type2000Reference
Dimensions
Wheelbase142 cmReference
Weight514 kgReference
Front tire18x8.50-10Reference
Rear tire26x12.00-12Reference
Lawn/turf front18x8.50-10Reference
Lawn/turf rear26x12.00-12Reference
Length200 cmReference
Width122 cmReference
Height130 cmReference
John Deere X729 attachments
48" mid-mount mower deckReference
54" mid-mount mower deckReference
62" mid-mount mower deckReference
X729 Serial Number Location
Serial number on the center-right of main tractor frame, just behind hydraulic couplers.Reference
X729 Serial Numbers
2008030001Reference
2009040001Reference
2010050001Reference
2011060001Reference
2012070001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps20Reference
Charging amps40Reference
Battery CCA340Reference
Battery volts12Reference
Attachment overview
48" mid-mount mower deckReference
54" mid-mount mower deckReference
62" mid-mount mower deckReference
Speeds
26-inch tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
