Tractor · 2007Unverified
Kioti CK20S
Kioti CK20S — CK Series · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
2125 to 2138 pounds
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Compact Utility tractorReference
Built in Daegu, South KoreaReference
Four-wheel driveReference
Differential lockstandardReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Foldable ROPS. Canopy optional.Reference
Engine
Daedong 1.0L 3-cyl dieselReference
Fuel tank20.0 LReference
Engine (gross)16.4 kWReference
Daedong 3Cl100LWBReference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.0 LReference
Bore/Stroke75 x 76 mmReference
Power (gross)16.4 kWReference
Pre-heatingglow plugsReference
Rated RPM2800Reference
Starter typeelectricReference
Transmission
6-speed partially synchronizedReference
hydrostaticReference
Typepartially synchronizedReference
Gears6 forward and 2 reverseReference
First gear synchronized from forward to reverse.Reference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
Gear PTO (claimed)12.8 kWReference
Hydro PTO (claimed)12.1 kWReference
Valves1 (optional)Reference
Total flow29.0 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)591 kgReference
Rear PTOtransmission (CK20S)Reference
Rear PTOindependent (CK20S HST)Reference
Rear PTO Type540Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Dimensions
Wheelbase144 cmReference
Weight2125 to 2138 poundsReference
Front tire6-12Reference
Rear tire9.5-16Reference
Weight469 kgReference
Ag front6-12Reference
Ag rear9.5-16Reference
Lawn/turf front23x8.5-12Reference
Lawn/turf rear33x12.5-16.5Reference
Industrial front23x8.5-12Reference
Industrial rear12-16.5Reference
Length268 cmReference
Width112 cmReference
Height (ROPS)218 cmReference
Weight963 kgReference
Weight969 kgReference
Ground clearance30 cmReference
Front tread90 cmReference
Rear tread88 to 93 cmReference
Kioti CK20S attachments
front-end loaderReference
backhoeReference
Attachment overview
Front-end loaderReference
BackhoeReference
Kioti KB2465 Backhoe
Backhoe typeKioti KB2465 BackhoeReference
2-Foot flat digging depth193 cmReference
Reach from pivot287 cmReference
Loading height161 cmReference
Bucket force1278 kgReference
Dipperstick force792 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
