Kioti CK22
Kioti CK22 — Sub-Compact Utility tractor · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
904 kg
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Sub-Compact Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Daedong 1.0L 3-cyl dieselReference
Fuel tank20.1 LReference
Engine (gross)16.4 kWReference
Daedong 3C100AReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.0 LReference
Bore/Stroke75 x 76 mmReference
Power (gross)16.4 kWReference
Rated RPM2800Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
Typeopen centerReference
Rear valves1Reference
Mid valves2Reference
Total flow29.1 lpmReference
Rear TypeIReference
Rear lift (at ends)503 kgReference
Rear PTO Type540Reference
Mid PTO Type2000Reference
Dimensions
Wheelbase147 cmReference
Weight904 kgReference
Front tire6-12Reference
Rear tire9.5-16Reference
Standard tires (ag)Front: 6-12. Rear: 9.5-16Reference
Length268 cmReference
Width112 cmReference
Height (ROPS)218 cmReference
Ground clearance30 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
