Kioti CK2510
Kioti CK2510 — Model year 2014-20152016-2025 · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1025 kg
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockrear standardReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post foldable ROPS.Reference
Engine
Daedong 1.4L 3-cyl dieselReference
Fuel tank25.0 LReference
Engine (gross)18.3 kWReference
Daedong 3A139LFBReference
dieselReference
3-cylinder 6-valveReference
liquid-cooled inlineReference
Displacement1.4 LReference
Bore/Stroke80 x 92 mmReference
EmissionsTier IVReference
Power (gross)18.3 kWReference
Fuel systemindirect injectionReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
hydrostaticReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
Gear PTO (claimed)14.9 kWReference
Hydro PTO (claimed)14.8 kWReference
Typeopen center gear pumpReference
Valves1 (optional)Reference
Pump flow42.8 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at 24"/610mm)545 kgReference
Gear Rear PTOtransmissionReference
Hydro Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Dimensions
Wheelbase151 cmReference
Weight1025 kgReference
Front tire7.0-12Reference
Rear tire11.2-16Reference
Weight459 kgReference
Ag front7.0-12Reference
Ag rear11.2-16Reference
Lawn/turf front23x8.5-12Reference
Lawn/turf rear33x12.5-16.5Reference
Industrial front23x8.5-12Reference
Industrial rear12-16.5Reference
Length277 cmReference
Width124 cmReference
Height (ROPS)210 cmReference
Ground clearance34 cmReference
Front tread96 cmReference
Rear tread94 cmReference
Kioti CK2510 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Kioti KB2465 Backhoe
Backhoe typeKioti KB2465 BackhoeReference
2-Foot flat digging depth193 cmReference
Reach from pivot287 cmReference
Loading height161 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1278 kgReference
Dipperstick force792 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
