Tractor · 2021Unverified
Kioti CK2610SE
Kioti CK2610SE — CK Series · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1540 kg
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Cab standard with air-conditioning..Reference
Engine
Daedong 1.6L 3-cyl dieselReference
Fuel tank34.1 LReference
Engine (gross)18.3 kWReference
Daedong 3A165Reference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.6 LReference
Bore/Stroke87 x 92 mmReference
Power (gross)18.3 kWReference
Fuel systemcommon rail direct injectionReference
Air cleanerdry dual elementReference
Pre-heatingblock heaterReference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
PTO (claimed)14.0 kWReference
Typeopen centerReference
Rear valves2 or 3Reference
Pump flow39.4 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at 24"/610mm)739 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Dimensions
Wheelbase166 cmReference
Weight1540 kgReference
Front tire7-16Reference
Rear tire11.2-24Reference
Weight442 kgReference
Ag front7-16Reference
Ag rear11.2-24Reference
Lawn/turf front28x8.5-15Reference
Lawn/turf rear41x14-20Reference
Industrial front27x8.5-15Reference
Industrial rear15-19.5Reference
Length307 cmReference
Width138 cmReference
Height (cab)234 cmReference
Ground clearance34 cmReference
Front tread122 cmReference
Rear tread120 cmReference
Kioti CK2610SE attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Kioti KB2475L Backhoe
Backhoe typeKioti KB2475L BackhoeReference
Transport height212 cmReference
2-Foot flat digging depth227 cmReference
Reach from pivot317 cmReference
Loading height183 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force954 kgReference
Dipperstick force1278 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
