Tractor · 2008Unverified

Kioti CK27

Name: Kioti CK27
Brand: Kioti

Kioti CK27 — CK Series · 28 hp. Reference specifications; pending source verification.

The Kioti CK27 is a tractor with an approximate engine power rating of 28 hp, positioning it at the lower end of its class. It was manufactured from 2008 to 2014. The tractor is equipped with a 3-cylinder diesel liquid-cooled engine and four-wheel drive, paired with a hydrostatic transmission. Its operating weight is specified as 3117 to 3161 pounds, suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

28 hp

Max power

28 hp

Weight

3117 to 3161 pounds

Catalogue coverage

Variants represented

Richest spec table

104 rows

Recorded power

28 hp

Recorded weight

484 kg

Transmissions

8-speed synchronized shuttle

Production years

2008-2014

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerKioti (a part of Daedong)Reference

Compact Utility tractorReference

Built in Daegu, South KoreaReference

Four-wheel driveReference

Differential lockstandardReference

Power steeringReference

Wet disc brakesReference

Foldable ROPS. Canopy optional.Reference

Variants

CK27gearReference

CK27HSThydrostaticReference

Engine

Daedong 1.4L 3-cyl dieselReference

Fuel tank29.9 LReference

Engine (gross)20.9 kWReference

Daedong 3A139LWMReference

dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement1.4 LReference

Bore/Stroke80 x 92 mmReference

EmissionsTier IIIReference

Power (gross)20.9 kWReference

Pre-heatingglow plugsReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed2,600 RPMReference

Emissions complianceTier IIIReference

Bore and stroke3.15x3.64 inchesReference

Cooling systemliquid-cooledReference

Transmission

8-speed synchronized shuttleReference

hydrostaticReference

Gear Weight1433 kgReference

Typesynchronized shuttleReference

Gears8 forward and reverseReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Transmission TypeSync ShuttleReference

Wheel Drive4 WDReference

PTO & Hydraulics

Gear PTO (claimed)16.2 kWReference

Hydro PTO (claimed)15.3 kWReference

Valves0 to 2Reference

Total flow48.1 lpmReference

Rear TypeIReference

Rear lift (at 24"/610mm)800 kgReference

Rear PTOliveReference

Rear PTO Type540Reference

Rear PTO Type1000 (optional)Reference

Mid PTOoptionalReference

Mid PTO Type2000Reference

Dimensions

Wheelbase167 cmReference

Weight3117 to 3161 poundsReference

Front tire7-14Reference

Rear tire11.2-24Reference

Weight484 kgReference

Ag front7-14Reference

Ag rear11.2-24Reference

Lawn/turf front27x8.50-15Reference

Lawn/turf rear41x14.00-20Reference

Industrial front25x8.50-14Reference

Industrial rear15-19.5Reference

Length310 cmReference

Width138 cmReference

Height (ROPS)245 cmReference

Hydro Weight1413 kgReference

Ground clearance35 cmReference

Front tread110 cmReference

Rear tread97 to 130 cmReference

Kioti CK27 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Kioti KB2475 Backhoe

Backhoe typeKioti KB2475 BackhoeReference

2-Foot flat digging depth227 cmReference

Reach from pivot317 cmReference

Loading height183 cmReference

Bucket force1277 kgReference

Dipperstick force954 kgReference

General

Make & ModelKioti (a part of Daedong)Reference

Cruise controlAvailableReference

SCV controlJoystickReference

Rollover protective structureFoldable ROPS.Reference

Country of manufacturerSouth KoreaReference

Capacities

Capacity85 ciReference

Power

Max Power28 hpReference

PTO

PTO Power21.7 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM1,000 RPMReference

Mid PTO RPM2,000 RPMReference

Steering & brakes

Brakeswet discReference

Steering typepowerReference

Hydraulics

Pump Rated Output (total)12.7 gpmReference

Remote Valves0 to 2 ValvesReference

Rear Hitch category (SAE designation)Category IReference

Dimensions & weight

Height Over ROPS245.9 cmReference

Overall Length310.4 cmReference

Overall Width139.7 cmReference

Overall weight1,413.8 kgReference

Wheels & tyres

Rear wheel tread range38.2 to 51.3 inchesReference

Front Wheel tread range110.5 cmReference

Operator station

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
