Tractor · 2004Unverified
Kioti CK30
Kioti CK30 — Model year 2004-20072008-2014 · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
3042 to 3055 pounds
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Compact Utility tractorReference
Built in Daegu, South KoreaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Canopy optional.Reference
Variants
CK30gearReference
CK30HSThydrostaticReference
Engine
Daedong 1.5L 3-cyl dieselReference
Fuel tank29.9 LReference
Engine (gross)22.4 kWReference
Daedong 3A150DReference
dieselReference
3-cylinderReference
liquid-cooledReference
Engine model 3A150E used on the CK30HST.Reference
Displacement1.5 LReference
Bore/Stroke83 x 92 mmReference
EmissionsTier IIReference
Power (gross)22.4 kWReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
Starter volts12Reference
Oil capacity5.8 LReference
Transmission
8-speed synchronized shuttleReference
hydrostaticReference
16-speed creeperReference
Gear Weight1379 kgReference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
Oil capacity27.0 LReference
Four synchronized gears in two ranges with mechanical shuttle. Shuttle and gear shifts can be made while moving, using the clutch. Tractor must be stopped, and clutch used, to shift range.Reference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
Oil capacity30.0 LReference
TypecreeperReference
Gears16 forward and reverseReference
Creeper option provides an additional low range to the entire transmission.Reference
PTO & Hydraulics
Gear PTO (claimed)17.2 kWReference
Hydro PTO (claimed)16.4 kWReference
Typeopen centerReference
Valves0 to 2Reference
Total flow48.1 lpmReference
Rear TypeIReference
Controlposition controlReference
Controldraft control optionalReference
Rear lift (at 24"/610mm)800 kgReference
Rear PTOlive (two-stage clutch)Reference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2520Reference
Engine RPM1000@2520Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Engine RPM2000@2499Reference
Dimensions
Wheelbase167 cmReference
Weight3042 to 3055 poundsReference
Front tire7-14Reference
Rear tire11.2-24Reference
Ag front7-14Reference
Ag rear11.2-24Reference
Lawn/turf front27x8.50-15Reference
Lawn/turf rear41x14.00-20Reference
Industrial front25x8.50-14Reference
Industrial rear15-19.5Reference
Length310 cmReference
Width138 cmReference
Height (ROPS)245 cmReference
Hydro Weight1385 kgReference
Ground clearance35 cmReference
Front tread110 cmReference
Rear tread97 to 130 cmReference
Kioti CK30 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Battery CCA630Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Kioti KB2365 Backhoe
Backhoe typeKioti KB2365 BackhoeReference
Kioti KB2375 Backhoe
Backhoe typeKioti KB2375 BackhoeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
