Tractor · 2014Unverified
Kioti CK3010
Kioti CK3010 — Compact Utility tractor · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1025 kg
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Compact Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Daedong 1.4L 3-cyl dieselReference
Fuel tank25.0 LReference
Engine (gross)20.9 kWReference
Daedong 3A139LWDReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.4 LReference
Bore/Stroke80 x 92 mmReference
Power (gross)20.9 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
hydrostaticReference
TypegearReference
Gears6 forward and 2 reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
Typeopen centerReference
Pump flow42.8 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at 24"/610mm)335 kgReference
Rear PTOtransmissionReference
Rear PTOliveReference
Rear PTO Type540Reference
Mid PTO Type2000Reference
Dimensions
Wheelbase151 cmReference
Weight1025 kgReference
Front tire7-12Reference
Rear tire11.2-16Reference
Standard tires (ag)Front: 7-12. Rear: 11.2-16Reference
Length278 cmReference
Width124 cmReference
Height (ROPS)210 cmReference
Ground clearance33 cmReference
Front tread99 cmReference
Rear tread94 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
