Tractor · 2015Unverified
Kioti CK3510
Kioti CK3510 — CK10 Series · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
2679 to 3307 pounds
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab with air-conditioning optional (CK3510SE HC model).Reference
Variants
CK3510SE HCcab hydroReference
Engine
Daedong 1.8L 3-cyl dieselReference
Fuel tank34.1 LReference
Engine (gross)26.0 kWReference
Daedong 3F183Reference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.8 LReference
Bore/Stroke87 x 102 mmReference
Power (gross)26.0 kWReference
Fuel systemcommon rail direct injectionReference
Rated RPM2600Reference
Torque115.0 NmReference
Torque RPM1800Reference
StarterelectricReference
Starter volts12Reference
Transmission
9-speed gearReference
hydrostaticReference
Gear ROPS1215 kgReference
TypegearReference
Gears9 forward and 3 reverseReference
Clutchdry discReference
TypehydrostaticReference
Gearsinfinte forward and reverseReference
PTO & Hydraulics
Gear PTO (claimed)23.0 kWReference
Hydro PTO (claimed)22.1 kWReference
Typeopen centerReference
Valves2Reference
Total flow44.3 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at 24"/610mm)739 kgReference
Rear PTOliveReference
Clutchdry discReference
Rear PTO Type540 (1.375)Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Dimensions
Wheelbase166 cmReference
Weight2679 to 3307 poundsReference
Front tire7-16Reference
Rear tire11.2-24Reference
Weight453 kgReference
Standard tires (ag)Front: 7-16. Rear: 11.2-24Reference
Lawn/turf front28x8.5-15Reference
Lawn/turf rear41x14-20Reference
Industrial front27x8.5-15Reference
Industrial rear15-19.5Reference
Length307 cmReference
Width139 cmReference
Width160 cmReference
Height (ROPS)251 cmReference
Height (cab)232 cmReference
Ground clearance34 cmReference
Front tread113 cmReference
Rear tread130 cmReference
Hydro ROPS1240 kgReference
Hydro Cab1500 kgReference
Kioti CK3510 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Kioti KB2475L Backhoe
Backhoe typeKioti KB2475L BackhoeReference
Transport height212 cmReference
2-Foot flat digging depth227 cmReference
Reach from pivot317 cmReference
Loading height183 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1232 kgReference
Dipperstick force954 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
