Tractor · 2017Unverified

Kioti CK4010SE

Name: Kioti CK4010SE
Brand: Kioti

Kioti CK4010SE — CK Series · 40 hp. Reference specifications; pending source verification.

The Kioti CK4010SE is a compact tractor model with a 40 hp engine rating. Manufactured from 2017 to 2022, it features a 3-cylinder diesel liquid-cooled engine that powers four-wheel drive through a hydrostatic transmission. The CK4010SE weighs between 2906 and 3397 pounds. It is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

40 hp

Weight

2906 to 3397 pounds

Catalogue coverage

Variants represented

Richest spec table

80 rows

Recorded power

40 hp

Recorded weight

442 kg

Transmissions

12-speed synchro shuttle

Production years

2017-2022

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerKioti (a part of Daedong)Reference

Compact Utility tractorReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Two-post folding ROPS.Reference

Engine

Daedong 1.8L 3-cyl dieselReference

Fuel tank34.1 LReference

Engine (gross)29.5 kWReference

Daedong 3H-TH4BReference

dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement1.8 LReference

Bore/Stroke87 x 102 mmReference

Power (gross)29.5 kWReference

Fuel systemcommon rail direct injectionReference

Air cleanerdry dual elementReference

Pre-heatingblock heaterReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed synchro shuttleReference

hydrostaticReference

Typesynchro shuttleReference

Gears12 forward and reverseReference

Clutchdry discReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

Gear PTO (claimed)26.0 kWReference

Hydro PTO (claimed)24.8 kWReference

Typeopen centerReference

Rear valves2 or 3Reference

Pump flow42.8 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at 24"/610mm)739 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTOindependentReference

Mid PTO Type2000Reference

Dimensions

Wheelbase166 cmReference

Weight2906 to 3397 poundsReference

Front tire7-16Reference

Rear tire11.2-24Reference

Weight442 kgReference

Ag front7-16Reference

Ag rear11.2-24Reference

Lawn/turf front28x8.5-15Reference

Lawn/turf rear41x14-20Reference

Industrial front27x8.5-15Reference

Industrial rear15-19.5Reference

Length307 cmReference

Width138 cmReference

Height (ROPS)235 cmReference

Height (cab)234 cmReference

Ground clearance34 cmReference

Front tread122 cmReference

Rear tread120 cmReference

ROPS shuttle1318 kgReference

ROPS hydro1324 kgReference

Cab hydro1540 kgReference

Kioti CK4010SE attachments

snowblowerReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

SnowblowerReference

Front-end loaderReference

BackhoeReference

Kioti KB2475L Backhoe

Backhoe typeKioti KB2475L BackhoeReference

Transport height212 cmReference

2-Foot flat digging depth227 cmReference

Reach from pivot317 cmReference

Loading height183 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force954 kgReference

Dipperstick force1278 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
