Tractor · 2016Unverified

Kioti CS2210

Name: Kioti CS2210
Brand: Kioti

Kioti CS2210 — Model year 2016-20192020-2025 · 21 hp. Reference specifications; pending source verification.

The Kioti CS2210 is a compact tractor with a rated output of 21 hp. Produced from 2016 to 2025, it features a 3-cylinder diesel liquid-cooled engine, which powers four-wheel drive through a hydrostatic transmission. The listed weight of the CS2210 is 673 kg. It is designed for tasks that typically cover areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

21 hp

Max power

21 hp

Weight

673 kg

Catalogue coverage

Variants represented

Richest spec table

97 rows

Recorded power

21 hp

Recorded weight

673 kg

Transmissions

hydrostatic

Production years

2016-2025

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerKioti (a part of Daedong)Reference

Sub-Compact Utility tractorReference

Four-wheel driveReference

Final drivesmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional.Reference

Engine

Shibaura 1.1L 3-cyl dieselReference

Fuel tank25.4 LReference

Engine (gross)15.7 kWReference

Shibaura S773L-F21Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.1 LReference

Bore/Stroke77 x 81 mmReference

Power (gross)15.7 kWReference

Compression24:1Reference

Rated RPM3000Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

Rated engine speed3,200 rpmReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverseReference

Transmission TypeHSTReference

forward and reverse optionsInfinite, 2 RangeReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)13.9 kWReference

Typeopen centerReference

Total flow24.6 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at 24"/610mm)317 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Mid PTOindependentReference

Mid PTO Type2200Reference

Dimensions

Wheelbase139 cmReference

Weight673 kgReference

Weight327 kgReference

Industrial front18x8.5-10Reference

Industrial rear26x12.00-12Reference

Length252 cmReference

Width118 cmReference

Height223 cmReference

Ground clearance16 cmReference

Front tread115 cmReference

Rear tread118 cmReference

Kioti CS2210 attachments

60" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

60" mid-mount mower deckReference

Front-end loaderReference

BackhoeReference

60" Mower deck

Typemid-mount Kioti SM2410Reference

Type3-bladeReference

Cutting width152 cmReference

Overall width186 cmReference

Cut height2 to 10 cmReference

Kioti SB2410L Backhoe

Backhoe typeKioti SB2410L BackhoeReference

Transport height172 cmReference

Bucket width20 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

2-Foot flat digging depth184 cmReference

Reach from pivot268 cmReference

Loading height150 cmReference

Bucket Rotation165°Reference

Swing Arc150°Reference

Bucket force954 kgReference

Dipperstick force536 kgReference

General

Make & Model3C100LWH-U3Reference

Cruise controltrueReference

Differential lockYesReference

Power

Max Power21 hpReference

PTO

PTO Power16.3 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 rpmReference

Mid PTO RPM2,200 rpmReference

Steering & brakes

BrakesWet Multi DiscReference

Steering typePower SteeringReference

Hydraulics

Pump Rated Output (total)24.6 l/minReference

Rear Hitch category (SAE designation)Category 1Reference

Rear Hitch maximum lift capacity317.5 kgReference

Dimensions & weight

Overall Length252.2 cmReference

Turning radius2.5 mReference

Overall weight673.6 kgReference

Wheels & tyres

Rear Wheel TypeTurf: 26 x 12.00 - 12\\r\\nIndustrial: 26 x 12.00 - 12Reference

Rear wheel tread range118.6 cmReference

Front Wheel TypeTurf: 18 x 8.5 - 10\\r\\nIndustrial: 18 x 8.5 - 10Reference

Front Wheel tread range115.1 cmReference

Operator station

Cab AvailabilityOptionalReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
