Tractor · 2020Unverified

Kioti CS2220

Name: Kioti CS2220
Brand: Kioti

Kioti CS2220 — CS Series · 21 hp. Reference specifications; pending source verification.

The Kioti CS2220 is a tractor with a rated output of 21 hp — making it one of the more compact options in its class. The CS2220 was produced in 2020. It is powered by a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a hydrostatic transmission. Listed weight is 704 kg, and it is aimed at jobs of around up to 200 ac. Recorded specifications in UK and US units are listed below.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

21 hp

Max power

21 hp

Weight

704 kg

Catalogue coverage

Variants represented

Richest spec table

95 rows

Recorded power

21 hp

Recorded weight

704 kg

Transmissions

hydrostatic

Production years

2020-2020

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerKioti (a part of Daedong)Reference

Compact Utility tractorReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Daedong 1.0L 3-cyl dieselReference

Fuel tank25.4 LReference

Engine (gross)15.7 kWReference

Daedong 3C100LWHReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.0 LReference

Bore/Stroke75 x 76 mmReference

Power (gross)15.7 kWReference

Rated RPM3200Reference

StarterelectricReference

Starter volts12Reference

Fuel TypeDieselReference

No of Cylinders3Reference

Rated engine speed3,200 rpmReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

Transmission TypeHSTReference

forward and reverse optionsInfinite, 2 RangeReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)12.2 kWReference

Typeopen centerReference

Pump flow26.4 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at 24"/610mm)317 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTOindependentReference

Mid PTO Type2200Reference

Dimensions

Wheelbase139 cmReference

Weight704 kgReference

Weight288 kgReference

Lawn/turf front18x8.50-10Reference

Lawn/turf rear26x12.00-12Reference

Industrial front18x8.50-10Reference

Industrial rear26x12.00-12Reference

Length252 cmReference

Width116 cmReference

Height (ROPS)223 cmReference

Ground clearance16 cmReference

Front tread116 cmReference

Rear tread116 cmReference

Kioti CS2220 attachments

54" mid-mount mower deckReference

60" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

54" mid-mount mower deckReference

60" mid-mount mower deckReference

Front-end loaderReference

BackhoeReference

Kioti SB2420 Backhoe

Backhoe typeKioti SB2420 BackhoeReference

Transport height172 cmReference

Bucket width20 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width60 cmReference

2-Foot flat digging depth184 cmReference

Reach from pivot268 cmReference

Loading height150 cmReference

Bucket Rotation165°Reference

Swing Arc150°Reference

Bucket force954 kgReference

Dipperstick force536 kgReference

General

Make & Model3C100LWH-U3Reference

Cruise controltrueReference

SCV controlJoystick: AvailableReference

Capacities

Capacity61.5 cu. in.Reference

Power

Max Power21 hpReference

PTO

PTO Power16.3 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 rpmReference

Steering & brakes

BrakesWet Multi DiscReference

Steering typePower SteeringReference

Hydraulics

Pump Rated Output (total)26.4 l/minReference

Rear Hitch category (SAE designation)Category 1Reference

Dimensions & weight

Overall Length252.2 cmReference

Overall Width116.6 cmReference

Turning radius2.5 mReference

Overall weight704.9 kgReference

Wheels & tyres

Rear Wheel TypeTurf: 26 x 12.00 - 12\\r\\nIndustrial: 26 x 12.00 - 12Reference

Rear wheel tread range116.8 cmReference

Front Wheel TypeTurf: 18 x 8.5 - 10\\r\\nIndustrial: 18 x 8.5 - 10Reference

Front Wheel tread range113.3 cmReference

Operator station

Cab AvailabilityOptionalReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
