Tractor · 2012Unverified
Kioti CS2410
Kioti CS2410 — CS Series · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
673 kg
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Sub-Compact Utility tractorReference
Four-wheel driveReference
Differential lockrear standardReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Shibaura 1.1L 3-cyl dieselReference
Fuel tank25.4 LReference
Engine (gross)18.3 kWReference
Shibaura S773LReference
dieselReference
3-cylinder 6-valveReference
liquid-cooled inlineReference
Displacement1.1 LReference
Bore/Stroke77 x 81 mmReference
EmissionsTier IVReference
Power (gross)18.3 kWReference
Fuel systemindirect injectionReference
Rated RPM3000Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
PTO (claimed)14.5 kWReference
Typeopen center gear pumpReference
Pump flow24.6 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at 24"/610mm)317 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOstandardReference
Mid PTO Type2200Reference
Dimensions
Wheelbase139 cmReference
Weight673 kgReference
Weight298 kgReference
Lawn/turf front18x8.5-10Reference
Lawn/turf rear26x12.00-12Reference
Industrial front18x8.5-10Reference
Industrial rear26x12.00-12Reference
Length249 cmReference
Width118 cmReference
Height (ROPS)223 cmReference
Ground clearance16 cmReference
Front tread116 cmReference
Rear tread127 cmReference
Kioti CS2410 attachments
60" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
60" Mower deck
Typemid-mount Kioti SM2410Reference
Type3-bladeReference
Cutting width152 cmReference
Overall width186 cmReference
Cut height2 to 10 cmReference
Kioti SB2410 Backhoe
Backhoe typeKioti SB2410 BackhoeReference
2-Foot flat digging depth213 cmReference
Reach from pivot289 cmReference
Loading height132 cmReference
Bucket Rotation163°Reference
Swing Arc150°Reference
Bucket force950 kgReference
Dipperstick force525 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
