Tractor · 2016Unverified
Kioti CS2510
Kioti CS2510 — Model year 2016-20192020-2025 · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
673 kg
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Sub-Compact Utility tractorReference
Four-wheel driveReference
Final drivesmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional.Reference
Engine
Shibaura 1.1L 3-cyl dieselReference
Fuel tank25.4 LReference
Engine (gross)18.3 kWReference
Shibaura S773LReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke77 x 81 mmReference
Power (gross)18.3 kWReference
Compression24:1Reference
Rated RPM3000Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
PTO (claimed)14.5 kWReference
Typeopen centerReference
Total flow24.6 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at 24"/610mm)317 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Mid PTOindependentReference
Mid PTO Type2200Reference
Dimensions
Wheelbase139 cmReference
Weight673 kgReference
Weight327 kgReference
Industrial front18x8.5-10Reference
Industrial rear26x12.00-12Reference
Length252 cmReference
Width118 cmReference
Height223 cmReference
Height (cab)212 cmReference
Ground clearance16 cmReference
Front tread115 cmReference
Rear tread118 cmReference
Kioti CS2510 attachments
60" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
60" Mower deck
Typemid-mount Kioti SM2410Reference
Type3-bladeReference
Cutting width152 cmReference
Overall width186 cmReference
Cut height2 to 10 cmReference
Kioti SB2410L Backhoe
Backhoe typeKioti SB2410L BackhoeReference
Transport height172 cmReference
Bucket width20 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
2-Foot flat digging depth184 cmReference
Reach from pivot268 cmReference
Loading height150 cmReference
Bucket Rotation165°Reference
Swing Arc150°Reference
Bucket force954 kgReference
Dipperstick force536 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
