Tractor · 2013Unverified

Kioti CS2610

Name: Kioti CS2610
Brand: Kioti

Kioti CS2610 — Sub-Compact Utility tractor · 26 hp. Reference specifications; pending source verification.

The Kioti CS2610 is a tractor with a rated power output of approximately 26 hp, positioning it at the lighter end of its class. It was first produced in 2013. The tractor is equipped with a 3-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. Its operating weight is listed at 673 kg, suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

26 hp

Max power

26 hp

Weight

673 kg

Catalogue coverage

Variants represented

Richest spec table

99 rows

Recorded power

26 hp

Recorded weight

673 kg

Transmissions

hydrostatic

Production years

2013-2013

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerKioti (a part of Daedong)Reference

Sub-Compact Utility tractorReference

Built in South KoreaReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Shibaura 1.1L 3-cyl dieselReference

Fuel tank25.4 LReference

Engine (gross)19.4 kWReference

Engine (net)17.9 kWReference

Shibaura S773LReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.1 LReference

Bore/Stroke77 x 81 mmReference

Power (net)17.9 kWReference

Power (gross)19.4 kWReference

Rated RPM3000Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed3,000 RPMReference

Bore and stroke3.03x3.19 inchesReference

Cooling systemliquid-cooledReference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

Transmission TypeHSTReference

forward and reverse optionsHydrostatic : Infinite (2-range ) Fand Infinite (2-range ) RReference

Wheel Drive4WDReference

PTO & Hydraulics

Typeopen centerReference

Pump flow24.6 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at 24"/610mm)317 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Mid PTO Type2200Reference

Dimensions

Wheelbase139 cmReference

Weight673 kgReference

Weight298 kgReference

Lawn/turf front18x8.5-10Reference

Lawn/turf rear26x12.00-12Reference

Industrial front18x8.5-10Reference

Industrial rear26x12.00-12Reference

Length249 cmReference

Width118 cmReference

Height (ROPS)223 cmReference

Ground clearance16 cmReference

Front tread116 cmReference

Rear tread127 cmReference

Kioti CS2610 attachments

152 cm mid-mount mower deckReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

152 cm mid-mount mower deckReference

BackhoeReference

60" Mower deck

Typemid-mount Kioti SM2410Reference

Type3-bladeReference

Cutting width152 cmReference

Overall width186 cmReference

Cut height2 to 10 cmReference

Kioti SB2410 Backhoe

Backhoe typeKioti SB2410 BackhoeReference

Transport height179 cmReference

2-Foot flat digging depth213 cmReference

Reach from pivot289 cmReference

Loading height132 cmReference

Bucket Rotation163°Reference

Swing Arc150°Reference

Bucket force950 kgReference

Dipperstick force525 kgReference

General

Make & ModelKioti (a part of Daedong)Reference

Cruise controlAvailableReference

Rollover protective structureTwo-post folding ROPSReference

Country of manufacturerSouth KoreaReference

Capacities

Capacity69 ciReference

Power

Max Power26 hpReference

Rated Power24 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Mid PTOAvailableReference

Mid PTO RPM2,200 RPMReference

Steering & brakes

BrakesWet DiscReference

Steering typePowerReference

Hydraulics

Hydraulics Typeopen centerReference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch Sensing Typeposition controlReference

Dimensions & weight

Height Over ROPS223.5 cmReference

Overall Length249.2 cmReference

Overall weight673.6 kgReference

Wheels & tyres

Rear Wheel TypeLawn/turf rear:26x12.00-12 | Industrial rear:26x12.00-12Reference

Rear wheel tread range127 cmReference

Front Wheel TypeLawn/turf front:18x8.5-10 | Industrial front:18x8.5-10Reference

Front Wheel tread range116.3 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
