Tractor · 2001Unverified
Kioti DK35
Kioti DK35 — DK Series · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1639 kg
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Compact Utility tractorReference
Built in Daegu, South KoreaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Daedong 1.6L 3-cyl dieselReference
Engine26.1 kWReference
Daedong 3A165Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke87 x 92 mmReference
Power26.1 kWReference
Rated RPM2700Reference
Starter volts12Reference
Transmission
8-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)21.1 kWReference
Hydraulic system29.5 LReference
Capacity29.5 LReference
Valves0 or 1Reference
Pump flow47.3 lpmReference
Steering flow17.8 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1029 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Engine RPM540@2451Reference
Mid PTO Type2000Reference
Engine RPM2000@2542Reference
Capacities
Fuel43.5 LReference
Dimensions
Wheelbase166 cmReference
Weight1639 kgReference
Front tire7-16Reference
Rear tire12.4-24Reference
Ag front7-16Reference
Ag rear12.4-24Reference
Lawn/turf front27x8.50-15Reference
Lawn/turf rear41x14-20Reference
Industrial front10x16.5Reference
Industrial rear14.9x24Reference
Length320 cmReference
Width145 cmReference
Height129 cmReference
Height (ROPS)234 cmReference
Ground clearance28 cmReference
Front tread122 cmReference
Rear tread104 to 135 cmReference
Kioti DK35 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
