Tractor · 2001Unverified
Kioti DK40
Kioti DK40 · 33 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Weight
1740 kg
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Built in Daegu, South KoreaReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Foldable ROPS.Reference
Engine
Daedong 2.0L 4-cyl dieselReference
Engine29.8 kWReference
Daedong 4A200BReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.0 LReference
Bore/Stroke83 x 92 mmReference
Power29.8 kWReference
Rated RPM2700Reference
Starter volts12Reference
Transmission
8-speedReference
16-speedReference
Gears8 forward and reverseReference
Gears16 forward and reverseReference
PTO & Hydraulics
PTO (claimed)24.9 kWReference
Hydraulic system29.5 LReference
Capacity29.5 LReference
Valves0 or 1Reference
Pump flow47.3 lpmReference
Steering flow17.8 lpmReference
Rear TypeIReference
Rear lift (at ends)1029 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Mid PTO Type2000Reference
Capacities
Fuel43.5 LReference
Dimensions
Wheelbase177 cmReference
Weight1740 kgReference
Front tire8-16Reference
Rear tire13.6-24Reference
Weight387 kgReference
Weight444 kgReference
Ag front8-16Reference
Ag rear13.6-24Reference
Lawn/turf front27x8.50-15Reference
Lawn/turf rear41x14-20Reference
Industrial front10x16.5Reference
Industrial rear14.9x24Reference
Length328 cmReference
Width150 cmReference
Height135 cmReference
Height (ROPS)239 cmReference
Ground clearance34 cmReference
Front tread122 cmReference
Rear tread115 to 146 cmReference
Kioti DK40 attachments
front-end loaderReference
backhoeReference
Attachment overview
Front-end loaderReference
BackhoeReference
Kioti KB2375 Backhoe
Backhoe typeKioti KB2375 BackhoeReference
Transport height172 cmReference
Bucket width22 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Bucket width91 cmReference
Digging depth294 cmReference
Reach from pivot294 cmReference
Loading height183 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1213 kgReference
Dipperstick force954 kgReference
Kioti KB2385 Backhoe
Backhoe typeKioti KB2385 BackhoeReference
Transport height229 cmReference
Bucket width22 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Bucket width91 cmReference
Digging depth259 cmReference
Reach from pivot326 cmReference
Loading height179 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1610 kgReference
Dipperstick force1009 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
