Tractor · 2010Unverified
Kioti DK451
Kioti DK451 — Compact Utility tractor · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
4167 to 4575 pounds
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Compact Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab available with air-conditioning.Reference
Engine
Daedong 2.2L 4-cyl dieselReference
Fuel tank57.9 LReference
Engine (gross)33.6 kWReference
Daedong 4A220LXBReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke87 x 92 mmReference
Power (gross)33.6 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchro shuttleReference
Typesynchro shuttleReference
Gears12 forward and reverseReference
Clutch260mm dry discReference
PTO & Hydraulics
Typeopen centerReference
Valves2Reference
Pump flow37.5 lpmReference
Total flow53.7 lpmReference
Steering flow16.3 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift (at ends)1203 kgReference
Rear PTOindependentReference
Rear PTO Type540/750/1000Reference
Dimensions
Wheelbase187 cmReference
Weight4167 to 4575 poundsReference
Front tire9.5-16Reference
Rear tire13.6-26Reference
Weight444 kgReference
Standard tires (ag)Front: 9.5-16. Rear: 13.6-26Reference
Length362 cmReference
Width153 cmReference
Height (ROPS)258 cmReference
Height (cab)233 cmReference
ROPS Weight1890 kgReference
Cab Weight2075 kgReference
Ground clearance41 cmReference
Front tread130 cmReference
Rear tread120 to 151 cmReference
Kioti DK451 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Kioti KB2385 Backhoe
Backhoe typeKioti KB2385 BackhoeReference
Transport height220 cmReference
2-Foot flat digging depth240 cmReference
Reach from pivot326 cmReference
Loading height200 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1610 kgReference
Dipperstick force1009 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
