Tractor · 2005Unverified
Kioti DK45S
Kioti DK45S — DK Series · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
4299 to 4585 pounds
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
Daedong 2.2L 4-cyl dieselReference
Fuel tank57.9 LReference
Engine (gross)33.6 kWReference
Daedong 4A220B-1Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke87 x 92 mmReference
Power (gross)33.6 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears12 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
Typeopen centerReference
Pump flow37.5 lpmReference
Steering flow16.3 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at 24"/610mm)1203 kgReference
Rear PTOindependentReference
ClutchelectricReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2507Reference
Front PTOindependentReference
Front PTO Type2600Reference
Dimensions
Wheelbase187 cmReference
Weight4299 to 4585 poundsReference
Lawn/turf front29x12.50-15Reference
Lawn/turf rear21.5-16.1Reference
Industrial front12-16.5Reference
Industrial rear17.5L-24Reference
Length324 cmReference
Width156 cmReference
Height (ROPS)258 cmReference
Height (cab)233 cmReference
ROPS Weight1950 kgReference
Cab Weight2079 kgReference
Ground clearance37 cmReference
Front tread120 cmReference
Rear tread101 to 121 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
