Tractor · 2003Unverified
Kioti DK55
Kioti DK55 — DK Series · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Weight
4685 to 5105 pounds
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Compact Utility tractorReference
Built in Daegu, South KoreaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Optional canopy. Optional cab with air-conditioning.Reference
Engine
Daedong 2.2L 4-cyl dieselReference
Fuel tank68.1 LReference
Engine (gross)41.0 kWReference
Daedong 4A220TReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke87 x 92 mmReference
Power (gross)41.0 kWReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
Starter volts12Reference
Transmission
12-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears12 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)33.7 kWReference
Pump flow37.5 lpmReference
Total flow53.7 lpmReference
Steering flow15.9 lpmReference
Rear TypeII/IReference
Rear lift (at 24"/610mm)1198 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase195 cmReference
Weight4685 to 5105 poundsReference
Front tire9.5-20/6Reference
Rear tire14.9-28Reference
Weight387 kgReference
Weight444 kgReference
Ag front9.5-20/6Reference
Ag rear14.9-28Reference
Lawn/turf front29x12.5x15/6Reference
Lawn/turf rear21.5Lx16.1/4Reference
Industrial front12x16.5/6Reference
Industrial rear17.5x24/8Reference
Length326 cmReference
Width176 cmReference
Height (ROPS)270 cmReference
Height (Folded ROPS)217 cmReference
Height (cab)264 cmReference
ROPS Weight2125 kgReference
Cab Weight2315 kgReference
Ground clearance44 cmReference
Front tread146 cmReference
Rear tread136 to 156 cmReference
Kioti DK55 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Kioti KB2375 Backhoe
Backhoe typeKioti KB2375 BackhoeReference
Transport height172 cmReference
Bucket width22 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Bucket width91 cmReference
Digging depth294 cmReference
Reach from pivot294 cmReference
Loading height183 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1213 kgReference
Dipperstick force954 kgReference
Kioti KB2385 Backhoe
Backhoe typeKioti KB2385 BackhoeReference
Transport height229 cmReference
Bucket width22 cmReference
Bucket width30 cmReference
Bucket width40 cmReference
Bucket width45 cmReference
Bucket width60 cmReference
Bucket width91 cmReference
Digging depth259 cmReference
Reach from pivot326 cmReference
Loading height179 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force1610 kgReference
Dipperstick force1009 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
