Tractor · 2015Unverified

Kioti DK5510

Name: Kioti DK5510
Brand: Kioti

Kioti DK5510 — DK10 Series · 55 hp. Reference specifications; pending source verification.

The Kioti DK5510 is a compact tractor with a rated output of 55 hp. It was produced in 2015 and features a 3-cylinder turbocharged diesel liquid-cooled engine. The tractor is equipped with four-wheel drive and an 8-speed gearbox, and has a listed weight of 1529 kg. It is suited to tasks covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

55 hp

Weight

1529 kg

Catalogue coverage

Variants represented

Richest spec table

72 rows

Recorded power

55 hp

Recorded weight

1529 kg

Transmissions

8-speed mechanical shuttle

Production years

2015-2015

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerKioti (a part of Daedong)Reference

Compact Utility tractorReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Daedong 1.8L 3-cyl dieselReference

Fuel tank45.0 LReference

Engine (gross)41.0 kWReference

Daedong 3F183TReference

turbocharged dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement1.8 LReference

Bore/Stroke87 x 102 mmReference

Power (gross)41.0 kWReference

Fuel systemcommon rail direct injectionReference

Rated RPM2600Reference

Torque181.0 NmReference

Torque RPM1700Reference

StarterelectricReference

Starter volts12Reference

Transmission

8-speed mechanical shuttleReference

8-speed power shuttleReference

Typemechanical shuttleReference

Gears8 forward and reverseReference

Clutchdry discReference

Typepower shuttleReference

PTO & Hydraulics

PTO (claimed)37.0 kWReference

Typeopen centerReference

Valves2Reference

Total flow54.9 lpmReference

Rear TypeIIReference

Rear TypeIReference

Controlposition controlReference

Rear lift (at 24"/610mm)1231 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Dimensions

Wheelbase181 cmReference

Weight1529 kgReference

Front tire8-16Reference

Rear tire13.6-24Reference

Weight494 kgReference

Standard tires (ag)Front: 8-16. Rear: 13.6-24Reference

Lawn/turf front29-12.5-15Reference

Lawn/turf rear21.5L-16.1Reference

Industrial front10-16.5Reference

Industrial rear14.9-24Reference

Length316 cmReference

Width159 cmReference

Height (ROPS)233 cmReference

Ground clearance38 cmReference

Front tread125 cmReference

Rear tread125 cmReference

Kioti DK5510 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

Kioti KL5510 loaderReference

Kioti KL5520 loaderReference

BackhoeReference

Kioti KB2485L Backhoe

Backhoe typeKioti KB2485L BackhoeReference

Transport height235 cmReference

2-Foot flat digging depth239 cmReference

Reach from pivot345 cmReference

Loading height203 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1700 kgReference

Dipperstick force1000 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
