Tractor · 2007Unverified

Kioti DK752

Name: Kioti DK752
Brand: Kioti

Kioti DK752 — Utility tractor · 72 hp. Reference specifications; pending source verification.

The Kioti DK752 is a tractor model with an engine rating of approximately 72 hp, situated within the mid-range capacity for its class. It was manufactured in 2007. Key features include a 4-cylinder diesel liquid-cooled engine, combined with four-wheel drive and a 16-speed gearbox. This model is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

72 hp

Max power

72.4 hp

Catalogue coverage

Variants represented

Richest spec table

87 rows

Recorded power

72 hp

Transmissions

16-speed synchromesh

Production years

2007-2007

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerKioti (a part of Daedong)Reference

Utility tractorReference

Built in South KoreaReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Cab standard with air-conditioning.Reference

Engine

Perkins 4.4L 4-cyl dieselReference

Fuel tank99.9 LReference

Engine (gross)54.0 kWReference

Perkins 1104C-44Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke105 x 127 mmReference

Power (gross)54.0 kWReference

Compression19.3:1Reference

Rated RPM2200Reference

Firing order1-3-4-2Reference

StarterelectricReference

Starter volts12Reference

Oil capacity10.5 LReference

Coolant capacity18.5 LReference

Fuel TypedieselReference

No of Cylinders4 cylinderReference

Rated engine speed2,200 RPMReference

Bore and stroke4.135x5.00 inchesReference

Compression ratio19.3:1Reference

Cooling systemliquid-cooledReference

Transmission

16-speed synchromeshReference

TypesynchromeshReference

Gears16 forward and reverseReference

Clutch325mm dry discReference

Oil capacity74.0 LReference

Transmission TypeSync ShuttleReference

forward and reverse optionsSynchromesh : 16F and 16 RReference

Wheel Drive4WDReference

PTO & Hydraulics

Typeopen centerReference

Valves2Reference

Pump flow45.4 lpmReference

Total flow77.2 lpmReference

Steering flow31.8 lpmReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift (at ends)2399 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Dimensions

Wheelbase230 cmReference

Front tire12.4-24Reference

Rear tire18.4-30Reference

Standard tires (ag)Front: 12.4-24. Rear: 18.4-30Reference

Length440 cmReference

Width198 cmReference

Height (cab)279 cmReference

Ground clearance42 cmReference

Front tread144 cmReference

Rear tread153 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

General

Make & ModelKioti (a part of Daedong)Reference

SCV controlJoystickReference

Country of manufacturerSouth KoreaReference

Capacities

Capacity268.5 ciReference

Crankcase oil volume11.1 qtsReference

Power

Max Power72.4 hpReference

PTO

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Steering & brakes

Brakeshydraulic wet discReference

Steering typepowerReference

Hydraulics

Pump Rated Output (total)20.4 gpmReference

Hydraulics Typeopen centerReference

Remote Valves2 ValvesReference

Steering & Implements flow8.4 gpm (12 gpm)Reference

Rear Hitch category (SAE designation)Category IIReference

Rear Hitch maximum lift capacity2,400 kgReference

Rear Hitch Sensing Typeposition and draft controlReference

Dimensions & weight

Height Over Cab279.4 cmReference

Overall Length440.9 cmReference

Overall Width198.6 cmReference

Wheels & tyres

Rear Wheel TypeRear: 18.4-30Reference

Rear wheel tread range153.4 cmReference

Front Wheel TypeFront: 12.4-24.Reference

Front Wheel tread range144 cmReference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
