Tractor · 2009Unverified

Kioti DS4510

Name: Kioti DS4510
Brand: Kioti

Kioti DS4510 — DS Series · 45 hp. Reference specifications; pending source verification.

The Kioti DS4510 is a tractor with a power output of approximately 45 hp, positioning it at the lower end of its class in terms of power. It was manufactured from 2009 to 2016. This tractor features a 4-cylinder diesel liquid-cooled engine, combined with four-wheel drive and an 8-speed gearbox. Its operating weight is listed as 1604 kg, and it is capable of handling operations on up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

45 hp

Max power

45 hp

Weight

1604 kg

Catalogue coverage

Variants represented

Richest spec table

94 rows

Recorded power

45 hp

Recorded weight

1604 kg

Transmissions

8-speed shuttle

Production years

2009-2016

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerKioti (a part of Daedong)Reference

Compact Utility tractorReference

Built in Daegu, South KoreaReference

Four-wheel driveReference

Differential lockrear standardReference

Power steeringReference

Wet disc brakesReference

Foldable ROPS. Optional canopy.Reference

Engine

Daedong 2.2L 4-cyl dieselReference

Fuel tank45.0 LReference

Engine (gross)33.6 kWReference

Daedong 4A220LWMReference

dieselReference

4-cylinderReference

liquid-cooled inlineReference

Displacement2.2 LReference

Bore/Stroke87 x 92 mmReference

EmissionsInterim Tier IVReference

Power (gross)33.6 kWReference

Air cleanerdry cartridgeReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders4 CylinderReference

Rated engine speed2,600 RPMReference

Emissions complianceInterim Tier IVReference

Bore and stroke3.43x3.64 inchesReference

Cooling systemliquid-cooledReference

Transmission

8-speed shuttleReference

TypeshuttleReference

Gears8 forward and reverseReference

Transmission TypeSync ShuttleReference

forward and reverse optionsShuttle : 8 F and 8 RReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)26.2 kWReference

Typeopen centerReference

Valves0 to 2Reference

Total flow49.9 lpmReference

Rear TypeIReference

Rear lift (at 24"/610mm)1099 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Dimensions

Wheelbase184 cmReference

Weight1604 kgReference

Front tire8-16Reference

Rear tire13.6-24Reference

Weight499 kgReference

Ag front8-16Reference

Ag rear13.6-24Reference

Lawn/turf front27x8.5-15Reference

Lawn/turf rear41x14-20Reference

Lawn/turf front29x12.5-15Reference

Lawn/turf rear21.5x16.1Reference

Industrial front10-16.5Reference

Industrial rear14.9-24Reference

Length312 cmReference

Width176 cmReference

Height (ROPS)258 cmReference

Ground clearance36 cmReference

Front tread138 cmReference

Rear tread127 to 147 cmReference

Kioti DS4510 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Kioti KB2485 Backhoe

Backhoe typeKioti KB2485 BackhoeReference

2-Foot flat digging depth239 cmReference

Reach from pivot345 cmReference

Loading height203 cmReference

Bucket force1700 kgReference

Dipperstick force1000 kgReference

General

Make & ModelKioti (a part of Daedong)Reference

Rollover protective structureFoldable ROPS.Reference

Country of manufacturerSouth KoreaReference

Capacities

Capacity134 ciReference

Power

Max Power45 hpReference

PTO

PTO Power35.1 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Steering & brakes

Brakeswet discReference

Steering typepowerReference

Hydraulics

Pump Rated Output (total)13.18 gpmReference

Hydraulics Typeopen centerReference

Remote Valves0 to 2 ValvesReference

Rear Hitch category (SAE designation)Category IReference

Dimensions & weight

Height Over ROPS258.1 cmReference

Overall Length312.4 cmReference

Overall Width176.5 cmReference

Overall weight1,604.8 kgReference

Wheels & tyres

Rear wheel tread range50.2 to 58.2 inchesReference

Front Wheel tread range138.9 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
