Tractor · 2008Unverified

Kioti EX45

Name: Kioti EX45
Brand: Kioti

Kioti EX45 — EX Series · 45 hp. Reference specifications; pending source verification.

The Kioti EX45 is a compact tractor with a rated output of 45 hp, produced from 2008 to 2013. It features a 4-cylinder diesel liquid-cooled engine, which drives the four-wheel drive system via a hydrostatic transmission. The listed weight of the tractor is 4387 to 4414 pounds. It is designed for tasks on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

45 hp

Max power

45 hp

Weight

4387 to 4414 pounds

Catalogue coverage

Variants represented

Richest spec table

90 rows

Recorded power

45 hp

Recorded weight

2002 kg

Transmissions

24-speed synchro shuttle

Production years

2008-2013

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerKioti (a part of Daedong)Reference

Compact Utility tractorReference

Built in South KoreaReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Cab standard with air-conditioning.Reference

Engine

Daedong 2.2L 4-cyl dieselReference

Fuel tank45.0 LReference

Engine (gross)33.6 kWReference

Daedong 4A220LWMReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.2 LReference

Bore/Stroke87 x 92 mmReference

Power (gross)33.6 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders4 cylinderReference

Rated engine speed2,600 RPMReference

Bore and stroke3.43x3.64 inchesReference

Cooling systemliquid-cooledReference

Transmission

24-speed synchro shuttleReference

hydrostaticReference

Typesynchro shuttleReference

Gears24 forward and reverseReference

Clutchdry discReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Transmission TypeHSTReference

Wheel Drive4WDReference

PTO & Hydraulics

Shuttle PTO (claimed)26.8 kWReference

Hydro PTO (claimed)25.4 kWReference

Typeopen centerReference

Pump flow57.9 lpmReference

Rear TypeIReference

Controlposition and draft controlReference

Rear lift (at ends)2940 kgReference

Rear lift (at 24"/610mm)2493 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Mid PTO Type2000Reference

Dimensions

Wheelbase187 cmReference

Weight4387 to 4414 poundsReference

Front tire9.5-16Reference

Rear tire13.6-26Reference

Standard tires (ag)Front: 9.5-16. Rear: 13.6-26Reference

Lawn/turf front29x12.5-15Reference

Lawn/turf rear21.5Lx16.1Reference

Industrial front12-16.5Reference

Industrial rear17.5L-24Reference

Length340 cmReference

Width175 cmReference

Height (cab)248 cmReference

Shuttle Weight2002 kgReference

Hydro Weight1989 kgReference

Ground clearance40 cmReference

Front tread136 cmReference

Rear tread136 to 151 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

General

Make & ModelKioti (a part of Daedong)Reference

Cruise controlAvailableReference

SCV controlJoystickReference

Country of manufacturerSouth KoreaReference

Capacities

Capacity134.1 ciReference

Power

Max Power45 hpReference

PTO

PTO Power35.9 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Mid PTOAvailableReference

Mid PTO RPM2,000 RPMReference

Steering & brakes

Brakeswet discReference

Steering typepowerReference

Hydraulics

Hydraulics Typeopen centerReference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch maximum lift capacity2,940 kgReference

Rear Hitch Sensing Typeposition and draft controlReference

Dimensions & weight

Height Over Cab248.4 cmReference

Overall Length340.9 cmReference

Overall Width175.8 cmReference

Overall weight2,002.2 kgReference

Wheels & tyres

Rear wheel tread range53.9 to 59.6 inchesReference

Front Wheel tread range136.4 cmReference

Operator station

Cab AvailabilityAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
