Tractor · 1987Unverified

Kioti LB2204

Name: Kioti LB2204
Brand: Kioti

Kioti LB2204 — Compact Utility tractor · 19 hp. Reference specifications; pending source verification.

The Kioti LB2204 is a tractor model with a rated power of 19 hp, positioning it at the lighter end of its class. Produced from 1987 to 1993, this model features a 3-cylinder diesel liquid-cooled engine and four-wheel drive with an 8-speed gearbox. The tractor has a listed operating weight of 1038 kg and is suitable for operations on up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

19 hp

Weight

1038 kg

Catalogue coverage

Variants represented

Richest spec table

67 rows

Recorded power

19 hp

Recorded weight

1038 kg

Transmissions

8-speed gear

Production years

1987-1993

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerKioti (a part of Daedong)Reference

Compact Utility tractorReference

Built in Daegu, South KoreaReference

Original price was $9,000 in 1988Reference

Four-wheel driveReference

Differential lockmechanical rearReference

SteeringmanualReference

Steeringpower assist optionalReference

Wet disc brakesReference

Two-post ROPS.Reference

Variants

LB22022WDReference

LB22044WDReference

Engine

Daedong 1.1L 3-cyl dieselReference

Engine16.4 kWReference

Daedong DH 1101-BReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.1 LReference

Bore/Stroke78 x 78 mmReference

Power16.4 kWReference

Pre-heatingglow plugsReference

Rated RPM2800Reference

Starter volts12Reference

Transmission

8-speed gearReference

TypegearReference

Gears8 forward and 2 reverseReference

ClutchdryReference

PTO & Hydraulics

PTO (claimed)14.2 kWReference

Typeopen centerReference

Total flow25.4 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift567 kgReference

Rear PTOtransmissionReference

ClutchoverrunningReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@2430Reference

Engine RPM1000@2430Reference

Front PTOengineReference

Front PTO Type2800Reference

Dimensions

Wheelbase164 cmReference

Weight1038 kgReference

Front tire6-14Reference

Rear tire9.5-24Reference

Ag front6-14Reference

Ag rear9.5-24Reference

Lawn/turf front25x8.50-14Reference

Lawn/turf rear13.6-16Reference

Length273 cmReference

Width130 cmReference

Height (exhaust)198 cmReference

Ground clearance25 cmReference

Front tread98 cmReference

Rear tread98 to 121 cmReference

LB2204 Serial Numbers

Location:On the tractor's transmission housing ahead of the clutch pedal.Reference

1986200001Reference

1987300001Reference

1988400001Reference

1989500001Reference

1990600001Reference

1991700001Reference

1992800001Reference

1993900001Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
