Tractor · 2007Unverified
Kioti LK30
Kioti LK30 · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
1314 kg
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Built in Daegu, South KoreaReference
Four-wheel driveReference
Differential lockstandardReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Foldable ROPS. Canopy optional.Reference
Engine
Daedong 1.5L 3-cyl dieselReference
Fuel tank28.0 LReference
Engine (gross)22.4 kWReference
Daedong 3A150LWBReference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.5 LReference
Power (gross)22.4 kWReference
Air cleanerdual stage cartridgeReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
Starter typeelectricReference
Transmission
8-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)17.2 kWReference
Valves0 or 1Reference
Total flow48.1 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)800 kgReference
Rear PTOlive (two-stage clutch)Reference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase164 cmReference
Weight1314 kgReference
Front tire7-14Reference
Rear tire11.2-24Reference
Ag front7-14Reference
Ag rear11.2-24Reference
Lawn/turf front27x8.50-15Reference
Lawn/turf rear41x14-20Reference
Industrial front25x8.5-14Reference
Industrial rear15-19.5Reference
Length282 cmReference
Width130 cmReference
Height (ROPS)225 cmReference
Ground clearance27 cmReference
Front tread110 cmReference
Rear tread102 to 126 cmReference
Kioti LK30 attachments
front-end loaderReference
backhoeReference
Attachment overview
Front-end loaderReference
BackhoeReference
Kioti KB2376 Backhoe
Backhoe typeKioti KB2376 BackhoeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
