The Kioti LK3504 is a compact tractor model with a rated output of 35 hp. It was manufactured from 1999 to 2002. The LK3504 is equipped with a 3-cylinder diesel liquid-cooled engine, which is connected to a four-wheel drive system through an 8-speed gearbox. The tractor's listed weight is 1437 kg, making it suitable for tasks covering areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
1437 kg
Catalogue coverage
Variants represented
2
Richest spec table
42 rows
Recorded power
35 hp
Recorded weight
1437 kg
Transmissions
8-speed synchronized shuttle
Production years
1999-2002
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Compact Utility tractorReference
Built in Daegu, South KoreaReference
Four-wheel driveReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Daedong 1.6L 3-cyl dieselReference
Engine (gross)26.1 kWReference
Daedong 3A165Reference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.6 LReference
Bore/Stroke87 x 92 mmReference
Power (gross)26.1 kWReference
Rated RPM2700Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)21.6 kWReference
Typeopen centerReference
Total flow30.3 lpmReference
Rear PTOlive (two-stage clutch)Reference
Rear PTO Type540/1000Reference
Front PTO Type2700Reference
Dimensions
Wheelbase166 cmReference
Weight1437 kgReference
Front tire9.5-16Reference
Rear tire14.9-24Reference
Ag front9.5-16Reference
Ag rear14.9-24Reference
Length286 cmReference
Width134 cmReference
Height (steering wheel)210 cmReference
Ground clearance29 cmReference
Front tread102 cmReference
Rear tread102 to 126 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
