Tractor · 2016Unverified
Kioti PX9510
Kioti PX9510 — Utility tractor · 90 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
90 hp
Weight
7716 to 8003 pounds
Hover a source tag to verify
Overview
ManufacturerKioti (a part of Daedong)Reference
Utility tractorReference
Built in South KoreaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab available with air-conditioning.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank120.0 LReference
Engine (gross)67.1 kWReference
Perkins 1104C-44TTGReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
Power (gross)67.1 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Transmission
16-speed synchro shuttleReference
32-speed power shuttleReference
Typesynchro shuttleReference
Gears16 forward and reverseReference
Clutchdry discReference
Typepower shuttleReference
Gears32 forward and reverseReference
Clutchwet discReference
PTO & Hydraulics
Typeopen centerReference
Valves4Reference
Pump flow48.4 lpmReference
Total flow79.1 lpmReference
Steering flow30.7 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at ends)2399 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase230 cmReference
Weight7716 to 8003 poundsReference
Front tire12.4-24Reference
Rear tire18.4-34Reference
Standard tires (ag)Front: 12.4-24. Rear: 18.4-34Reference
Length411 cmReference
Width199 cmReference
Height (ROPS)294 cmReference
Height (cab)276 cmReference
ROPS Weight3499 kgReference
Cab Weight3630 kgReference
Ground clearance49 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
